14 Replacement Parts List
<Model: CS-PV9CKE / CS-PV12CKE>
No. DESCRIPTION&NAME Q’ty CS-PV9CKE CS-PV12CKE RE
1 CHASSIS COMPLETE 1 CWD50C1354
←
←←
←
2 FAN MOTOR 1 CWA921181
←
←←
←
*
3 CROSS FLOW FAN COMPLETE 1 CWH02C1025
←
←←
←
4 EVAPORATOR 1 CWB30C1471 CWB30C1442
5 INTAKE AIR SENSOR HOLDER 1 CWH32050
←
←←
←
6 DISCHARGE GRILLE COMPLETE 1 CWE20C2191
←
←←
←
7 VERTICAL VANE 1 CWE24C1031
←
←←
←
8 VERTICAL VANE 1 CWE24C1032
←
←←
←
9 AIR SWING MOTOR 1 CWA98259
←
←←
←
*
10 CAP-DRAIN TRAY 1 CWH52062 CWH52061
11 HORIZONTAL VANE 1 CWE241073A
←
←←
←
12 PARTICULAR PIECE 1 CWD932168C
←
←←
←
13 CONTROL BOARD 1 CWH102201
←
←←
←
14 TERMINAL BOARD COMPLETE 1 CWA28C2155 CWA28C2152
15 POWER SUPPLY CORD 1 CWA20C2254
←
←←
←
16 MAIN PCB 1 CWA743325 CWA743326 *
17 RECEIVER 1 CWA73C1257
←
←←
←
*
18 SENSOR COMPLETE 1 CWA50C2064
←
←←
←
*
19 CONTROL BOARD FRONT COVER 1 CWH131102
←
←←
←
20 CONTROL BOARD TOP COVER 1 CWH131103
←
←←
←
21 INDICATOR 1 CWE39C1091
←
←←
←
*
22 INDICATOR PCB 1 CWA743279
←
←←
←
23 INDICATOR HOLDER 1 CWD932169
←
←←
←
24 REMOTE CONTROL COMPLETE 1 CWA75C2566
←
←←
←
*
25 FRONT GRILLE COMPLETE 1 CWE11C3020
←
←←
←
26 SCREW-FRONT GRILLE 2 XTT4+14C
←
←←
←
27 CAP-FRONT GRILLE 2 CWH521025F
←
←←
←
28 AIR FILTER 2 CWD001050
←
←←
←
29 DRAIN HOSE 1 CWH851033
←
←←
←
30 INSTALLATION PLATE 1 CWH36K1013
←
←←
←
31 BAG COMPLETE 1 CWH82C264
←
←←
←
32 OPERATION INSTRUCTIONS 1 CWF564222
←
←←
←
33 INSTALLATION INSTRUCTIONS 1 CWF612529
←
←←
←
34 INSTALLATION INSTRUCTIONS 1 CWF612530
←
←←
←
35 INSTALLATION INSTRUCTIONS 1 CWF612531
←
←←
←
Note:
1.All parts are supplied from GMAC, P.R. China.
2."*" marked parts are recommended to be kept in stock.
