2 Product Specifications
Unit CS-PV9CKE CU-PV9CKE
Cooling Capacity kW 2.65
Moisture Removal L/h 1.60
Power Source Phase
V
Cycle
Single
230
50
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Circulation Indoor Air (low) m
3
/min 5.8 —
Indoor Air (medium) m
3
/min 6.7 —
Indoor Air (high) m
3
/min 7.8 —
Outdoor Air m
3
/min — 34.5
Noise Level dB(A) High37, Low29 High50
Electrical Data Input W 820
Running Current A 3.60
EER W/W 3.23
Starting Current A 16.5
Piping Connection Port (Flare piping) Inch
Inch
G: half union 3/8"
L: half union 1/4"
G: 3-way valve 3/8"
L: 2-way valve 1/4"
Piping Size
(Flare piping)
Inch
Inch
G: gas side 3/8"
L: liquid side 1/4"
G: gas side 3/8"
L: liquid side 1/4"
Drain
Hose
Inner Diameter mm 12 —
Length m 0.6 —
Power Supply Cord Length (Number of core-wire) m 1.9
3 core-wire/1.5mm
2
—
—
Dimensions Height mm 275 540
Width mm 799 780
Depth mm 210 289
Net Weight kg 9.0 31
Compressor Type — Rotary(1 cylinder)
Rolling piston type
Motor Type — Induction(2 pole)
Rated Output W — 700
5
CS-PV9CKE CU-PV9CKE / CS-PV12CKE CU-PV12CKE
