5.2 Outdoor Unit
5.2.1 CU-RE9QKE
<Top View
>
<Front View><Side View>
<Side View>
Anchor Bolt Pitch
330 × 540
Space necessary for
installation
100 mm
100 mm
1000 mm
Unit : mm
3-way valve at Gas side
(Low Pressure)
2-way valve at Liquid side
(High Pressure)
69.6
(18)
61.6
542
11.5 289
24.4
(104.7) 60.5
155
84.8
34.5
570 104.9
780 67.6
