Panasonic CS-RE12QKE

97
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-RE9QKE CS-RE12QKE CS-RE15QKE REMARK
1 CHASSIS COMPLETE 1 CWD50C1653 ← ←
2 FAN MOTOR 1 L6CBYYYL0037 ← ← O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1076 ← ←
4 BEARING ASSY 1 CWH64K007 ← ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ← ←
7 EVAPORATOR 1 CWB30C4691 CWB30C4659 CWB30C4660
8 FLARE NUT (LIQUID) 1 CWT251030 ← ←
9 FLARE NUT (GAS) 1 CWT251031 ← CWT251032
10 CLIP FOR SENSOR 1 CWH32143 ← ←
11 CONTROL BOARD CASING 1 CWH102449 ← ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2364 ← ← O
13 ELECTRONIC CONTROLLER - MAIN 1 CWA73C8113 CWA73C8114 CWA73C8115 O
15
ELECTRONIC CONTROLLER -
INDICATOR
1 CWA746716 ← ← O
16 SENSOR COMPLETE 1 CWA50C2663 ← ← O
23 CONTROL BOARD TOP COVER 1 CWH131467 ← ←
24 INDICATOR HOLDER 1 CWD933406 ← ←
25
CONTROL BOARD FRONT COVER
CO.
1 CWH13C1247 ← ←
26 DISCHARGE GRILLE COMPLETE 1 CWE20C3236 ← ←
27 BACK COVER CHASSIS 1 CWD933233 ← ←
28 FULCRUM 1 CWH621131 ← ←
29 VERTICAL VANE 8 CWE241374 ← ←
30 CONNECTING BAR 2 CWE261251 ← ←
33 AIR SWING MOTOR 1 CWA981264 ← ← O
34 CAP - DRAIN TRAY 1 CWH521259 ← ←
35 HORIZONTAL VANE COMPLETE 1 CWE24C1385 ← ←
36 REMOTE CONTROL COMPLETE 1 CWA75C4455 ← ← O
37 FRONT GRILLE COMPLETE 1 CWE11C5832 ← ← O
38 INTAKE GRILLE COMPLETE 1 CWE22C1896 ← ←
39 GRILLE DOOR COMPLETE 1 CWE14C1090 ← ←
40 AIR FILTER 2 CWD001279 ← ← O
41 SCREW - FRONT GRILLE 2 XTT4+16CFJ ← ←
42 CAP - FRONT GRILLE 2 CWH521227 ← ←
43 DRAIN HOSE 1 CWH851173 ← ←
44 INSTALLATION PLATE 1 CWH361134 ← ←
45
BAG COMPLETE - INSTALLATION
SCREW
1 CWH82C1705 ← ←
46 OPERATING INSTRUCTION 1 CWF569459 ← ←
47 INSTALLATION INSTRUCTION 1 CWF616271 ← ←
48 INSTALLATION INSTRUCTION 1 CWF616272 ← ←
49 AIR PURIFYING FILTER 1 CWD00C1280 ← ← O
50 BAG 1 CWG861497 ← ←
51 SHOCK ABSORBER (L) 1 CWG713386 ← ←
52 SHOCK ABSORBER (R) 1 CWG713387 ← ←
53 C.C.CASE 1 CWG567355 ← ←
54 INSTALLATION INSTRUCTION 1 CWF616273 ← ←
55 INSTALLATION INSTRUCTION 1 CWF616274 ← ←
56 INSTALLATION INSTRUCTION 1 CWF616275 ← ←
57 INSTALLATION INSTRUCTION 1 CWF616276 ← ←
58 INSTALLATION INSTRUCTION 1 CWF616277 ← ←
