Panasonic CS-RE18SKUA

15
5.2 Outdoor Unit
5.2.1 CU-RE9SKUA CU-RE12SKUA
<Side View>
<Side View> <Front View>
<Top View>
Unit : inch
30-23/321
2-5/8
1/2
21-11/32
(3/4)
(2-3/4) (2-3/8)
11-13/32
1-3/86-1/8
3-3/8
22-1/2
(4-1/8)
4-1/8 2-3/8
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
Space necessary for
installation
Anchor Bolt Pitch
12-5/8 × 22-1/2
39-3/8
3-7/8
3-7/8
5.2.2 CU-RE18SKUA CU-RE24SKUA
Space necessary for
installation
Anchor Bolt Pitch
15-5/64 × 24-7/64
39-3/8
3-7/8
3-7/8
1-5/64
24-1/8 5-5/32
2-3/4
1-1/2
3-7/32
5-31/32
14-3/16
34-15/32
(5-5/32)
<Top View>
31-5/16
2-5/16
12-5/8
<Side View>
<Side View>
Unit: inch
<Front View>
2-61/64
2-17/32
(31/32)
2-3/4
