Panasonic CS-RE18SKUA

106
18.1.1.5 To Remove Control Board
12. Remove the 4 screws holding the
control board then pull out the
control board.
Figure 6
18.1.1.6 To Remove Cross Flow Fan and Indoor Fan Motor
13. Remove the screw that holding
the cross flow fan and fan motor
axis.
Figure 7
15. Remove the bearing by pulling it
out gently.
14. Remove the screw from the
evaporator.
Figure 8
