Panasonic CS-RE9PKE-3 Service Manual

7
Indoor CS-RE15PKE-3
Model
Outdoor CU-RE15PKE-3
Phase, Hz Single, 50
Power Supply
V 230
Min Rate Max
kW 1.00 4.20 4.60
BTU/h 3410 14330 15700
Capacity
kcal/h 860 3610 3960
Running Current A - 6.00 -
Input Power W 210 1260 1650
W/W 4.76 3.33 2.78
BTU/hW 16.23 11.37 9.51
EER
kcal/h/W 4.09 2.86 2.40
Pdesign C kW - 4.2 -
SEER (W/W) - 5.6 -
Annual Consumption kWh - 263 -
Erp
Class - - A+ -
Power Factor % 91
dB-A(H / L / QLo) Hi: 44 Lo: 31 QLo: 29
Indoor Noise
Power Level 60
dB-A (H / L ) Hi: 49 Lo: -
COOLING
Outdoor Noise
Power Level 65
kW 0.90 5.00 6.80
BTU/h 3070 17060 23200
Capacity
kcal/h 770 4300 5850
Running Current A - 6.30 -
Input Power W 210 1385 2280
W/W 4.28 3.61 2.98
BTU/hW 14.61 12.31 10.17
COP
kcal/hW 3.66 3.10 2.56
Pdesign H(A) kW - 3.6 -
Tbivalent
℃
- -10 -
SCOP (W/W) - 3.4 -
Annual Consumption kWh - 1482 -
Erp
Class - - A -
Power Factor % 95
dB-A(H / L / QLo) Hi: 46 Lo: 34 QLo: 28
Indoor Noise
Power Level 62
dB-A (H / L ) Hi: 51 Lo: -
HEATING
Outdoor Noise
Power Level 67
Max Current (A) / Max Input Power (W) 10.5 / 2.280k
Starting Current (A) 6.40
Standby Power (W) 7.5
Type Hermetic Motor compressor
Motor Type BRUSHLESS (6 poles)
Compressor
Output Power W 1100
Type Cross-flow fan
Material AS(GF30%)
Motor Type DC (8 poles)
Input Power W 36.66
Output Power W 30
Q-Lo rpm 730
Lo rpm 800
Me rpm 1020
Speed
(COOLING)
Hi rpm 1250
Q-Lo rpm 740
Lo rpm 900
Me rpm 1060
Indoor Fan
Speed
(HEATING)
Hi rpm 1300
Type Propeller
Material PP
Motor Type DC (8 poles)
Outdoor Fan
Input Power W 132.77

Panasonic CS-RE9PKE-3 Specifications

General

Indoor unit type	Wall-mountable
Indoor unit weight	8000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	750 m³/h
Heating airflow (indoor unit)	666 m³/h
Indoor unit dimensions (WxDxH)	848 x 213 x 290 mm
Type	Air conditioner indoor unit
Ionizer	-
Remotely operated	Yes
Refrigerating medium	R410A
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.4 l/h
Timer duration (maximum)	12 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3000 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	4100 W
Cooling energy efficiency (EER, W/W)	3.57
Heating energy efficiency (COP, W/W)	4.02
Seasonal efficiency rating (cooling) (SEER)	5.6
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	3.4
Noise level (low speed)	22 dB
Noise level (high speed)	58 dB
Noise level (medium speed)	42 dB
Power requirements	230V, 16A
Annual energy consumption	156 kWh
