Panasonic CS-RE9PKE-3 Service Manual

8
Output Power W 40
Hi(C) rpm 720
Speed
Hi(H) rpm 880
Moisture Removal L/h (Pt/h) 2.4 (4.2)
Q-Lo m
3
/min (ft
3
/m) 8.00(283)
Lo m
3
/min (ft
3
/m) 8.77(310)
Me m
3
/min (ft
3
/m) 11.18(395)
Indoor Airflow
(COOLING)
Hi m
3
/min (ft
3
/m) 13.7 (484)
Q-Lo m
3
/min (ft
3
/m) 8.25 (291)
Lo m
3
/min (ft
3
/m) 10.04 (354)
Me m
3
/min (ft
3
/m) 11.82 (417)
Indoor Airflow
(HEATING)
Hi m
3
/min (ft
3
/m) 14.5 (512)
Hi (Cooling) m
3
/min (ft
3
/m) 32.6 (1151)
Outdoor Airflow
Hi (Heating) m
3
/min (ft
3
/m) 32.6 (1151)
Control Device Capillary Tube
Refrigerant Oil cm
3
FV50S (320)
Refrigeration Cycle
Refrigerant Type g (oz) R410A, 920 (32.4)
Height(I/D / O/D) mm (inch) 290 (11-15/32) 540 (21-1/4)
Width (I/D / O/D) mm (inch) 848 (33-13/32) 780 (30-45/64)
Dimension
Depth (I/D / O/D) mm (inch) 213 (8-3/8) 289 (11-3/8)
Weight Net (I/D / O/D) kg (lb) 8.0 (18) 27 (59)
Pipe Diameter (Liquid / Gas)
mm (inch) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 5 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 10.0 (32.8)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7(23.0)
Inner diameter
mm 16
Drain Hose
Length mm 500
Fin Material Pre coated
Fin Type Slit Fin
Row x Stage x FPI 2 x 15 x 19
Indoor Heat
Exchanger
Size (W x H x L) mm 610 x 315 x 25.4
Fin Material Pre coated
Fin Type Slit Fin
Row x Stage x FPI 2 x 24 x 19
Outdoor Heat
Exchanger
Size (W x H x D) mm 777.9(749.3) x 504 x 18.19
Material PP-12X13H2
Air Filter
Type One-touch
Power Supply Indoor
Power Supply Cord A 16A
Thermostat -
Protection Device -
COOLING HEATING
TEMPERATURE (°C )
DB WB DB WB
Maximum 32 23 30 -
Indoor Operation Range
Minimum 16 11 16 -
Maximum 43 26 24 18
Outdoor Operation Range
Minimum -10 11 -15 -6
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19°C Wet Bu lb
(66.2°F Wet Bulb) and outdoor air temperature of 35 °C Dry Bulb (95.0°F Dry Bulb), 24°C Wet Bulb (75.2° F Wet
Bulb).
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor ai r
temperature of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb).
3. Specifications are subjected to change without prior notice for further improvement.

Panasonic CS-RE9PKE-3 Specifications

General

Indoor unit type	Wall-mountable
Indoor unit weight	8000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	750 m³/h
Heating airflow (indoor unit)	666 m³/h
Indoor unit dimensions (WxDxH)	848 x 213 x 290 mm
Type	Air conditioner indoor unit
Ionizer	-
Remotely operated	Yes
Refrigerating medium	R410A
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.4 l/h
Timer duration (maximum)	12 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3000 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	4100 W
Cooling energy efficiency (EER, W/W)	3.57
Heating energy efficiency (COP, W/W)	4.02
Seasonal efficiency rating (cooling) (SEER)	5.6
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	3.4
Noise level (low speed)	22 dB
Noise level (high speed)	58 dB
Noise level (medium speed)	42 dB
Power requirements	230V, 16A
Annual energy consumption	156 kWh
