133
REF. NO. PART NAME & DESCRIPTION QTY CS-S9MKQ CS-S12MKQ REMARK
1 CHASSY COMPLETE 1 CWD50C1653 ←
2 FAN MOTOR 1 CWA921443 ← O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1076 ←
4 BEARING ASSY 1 CWH64K007 ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ←
6 GENERATOR COMPLETE 1 CWH94C0028 ←
7 EVAPORATOR 1 CWB30C3357 CWB30C3362
8 FLARE NUT (LIQUID) 1 CWT251030 ←
9 FLARE NUT (GAS) 1 CWT251031 CWT251032
10 CLIP FOR SENSOR 1 CWH32143 ←
11 E-ION AIR PURIFYING SYSTEM 1 CWD93C1090 ←
12 CONTROL BOARD CASING 1 CWH102370 ←
13 TERMINAL BOARD COMPLETE 1 CWA28C2435 CWA28C2437 O
14 ELECTRONIC CONTROLLER - MAIN 1 CWA73C5309 CWA73C5310 O
15 ELECTRONIC CONTROLLER - POWER 1 CWA746250 ← O
16 ELECTRONIC CONTROLLER - HVU 1 CWA745348 ← O
17 ELECTRONIC CONTROLLER - INDICATOR 1 CWA746280 ← O
18 ELECTRONIC CONTROLLER - RECEIVER 1 CWA745288 ← O
19 SENSOR COMPLETE 1 CWA50C2401 ← O
20 CONTROL BOARD TOP COVER 1 CWH131350 ←
21 INDICATOR HOLDER 1 CWD933021 ←
22 CONTROL BOARD FRONT COVER CO. 1 CWH13C1183 ←
23 DISCHARGE GRILLE COMPLETE 1 CWE20C3123 ←
24 BACK COVER CHASSIS 1 CWD933233 ←
25 FULCRUM 1 CWH621102 ←
26 VERTICAL VANE 11 CWE241350 ←
27 CONNECTING BAR 1 CWE261152 ←
28 CONNECTING BAR 1 CWE261217 ←
29 CONNECTING BAR 1 CWE261216 ←
30 CONNECTING BAR 1 CWE261215 ←
31 AIR SWING MOTOR 1 CWA981264 ← O
32 AIR SWING MOTOR 1 CWA98K1015 ← O
33 CAP - DRAIN TRAY 1 CWH521096 ←
34 HORIZONTAL VANE COMPLETE 1 CWE24C1365 ←
35 REMOTE CONTROL COMPLETE 1 CWA75C3702 ← O
36 FRONT GRILLE COMPLETE 1 CWE11C4779 ← O
37 INTAKE GRILLE COMPLETE 1 CWE22C1677 ←
38 GRILLE DOOR 1 CWE14C1029 ←
39 E-ION FILTER 2 CWD00K1016 ←
40 SCREW - FRONT GRILLE 2 XTT4+16CFJ ←
41 CAP - FRONT GRILLE 2 CWH521194 ←
42 DRAIN HOSE 1 CWH851174 ←
43 INSTALLATION PLATE 1 CWH361097 ←
44 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
45 OPERATING INSTRUCTION 1 CWF567960 ←
46 INSTALLATION INSTRUCTION 1 CWF614750 ←
47 INSTALLATION INSTRUCTION 1 CWF614751 ←
49 ELECTRONIC CONTROLLER (COMPARATOR) 1 CWA746205 ← O
50
ELECTRONIC CONTROLLER (ECO SENSOR) -
LEFT
1 CWA745791 ← O
To Next Page
