Panasonic CS-S12MKQ Service Manual

5
2. Specification
Indoor CS-S9MKQ CS-S12MKQ
Model
Outdoor CU-S9MKQ CU-S12MKQ
Performance Test Condition JIS JIS
Phase, Hz Single, 60 Single, 60
Power Supply
V 220 230 220 230
Min. Mid. Max. Min. Mid. Max. Min. Mid. Max. Min. Mid. Max.
kW 0.84 2.65 3.20 0.84 2.65 3.20 0.92 3.23 4.00 0.92 3.23 4.00
BTU/h 2860 9040 10900 2860 9040 10900 3140 11000 13600 3140 11000 13600
Capacity
kJ/h 3020 9540 11520 3020 9540 11520 3310 11630 14400 3310 11630 14400
Running Current A - 3.4 - - 3.3 - - 4.1 - - 3.9 -
Input Power W 225 695 870 225 695 870 260 855 1.14k 260 855 1.14k
W/W 3.73 3.81 3.68 3.73 3.81 3.68 3.54 3.78 3.51 3.54 3.78 3.51
BTU/hW 12.71 13.01 12.53 12.71 13.01 12.53 12.08 12.87 11.93 12.08 12.87 11.93
EER
kJ/hW 13.42 13.73 13.24 13.42 13.73 13.24 12.73 13.60 12.63 12.73 13.60 12.63
Power Factor % - 93 - - 92 - - 95 - - 95 -
Indoor Noise (H / L / QLo) dB-A 36 / 26 / 23 36 / 26 / 23 38 / 28 / 25 38 / 28 / 25
Cooling
Outdoor Noise (H / L) dB-A 46 / - / - 47 / - / - 47 / - / - 48 / - / -
Max Current (A) / Max Input Power (W) 5.8 / 1.04k 7.2 / 1.35k
Starting Current (A) 3.4 4.1
Type Hermetic Motor Hermetic Motor
Motor Type Brushless (6 poles) Brushless (6 poles)
Compressor
Output Power W 650 650
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type Induction (4 poles) Induction (4 poles)
Input Power W - -
Output Power W 16 16
QLo rpm 680 720
Lo rpm 750 790
Me rpm 880 930
Hi rpm 1020 1070
Indoor Fan
Speed
SHi rpm 1130 1130
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6 poles) Induction (6 poles)
Input Power W - -
Output Power W 20 28
Outdoor Fan
Speed Hi rpm 790 - 820 790 - 820
Moisture Removal L/h (Pt/h) 1.6 (3.4) 1.8 (3.8)
QLo m
3
/min (ft
3
/min) 5.8 (205) 6.6 (233)
Lo m
3
/min (ft
3
/min) 6.6 (233) 7.4 (261)
Me m
3
/min (ft
3
/min) 8.0 (282) 9.0 (318)
Hi m
3
/min (ft
3
/min) 9.6 (340) 10.5 (370)
Indoor Airflow
SHi m
3
/min (ft
3
/min) 10.8 (381) 11.2 (395)
Outdoor
Airflow
Hi m
3
/min (ft
3
/min) 22.0 (780) 22.9 (810) 31.2 (1100) 32.6 (1150)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
FV50S (320) FV50S (320)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 760 (26.8) R410A, 850 (30.0)
