140
REF. NO. DESCRIPTION & NAME QTY CU-S9MKQ CU-S12MKQ REMARK
1 CHASSY ASSY 1 CWD50K2107 CWD50K2071
2 FAN MOTOR BRACKET 1 CWD541074 CWD541030
3 SCREW - FAN MOTOR BRACKET 2 CWH551217 ←
4 FAN MOTOR 1 CWA951604 CWA951466 O
5 SCREW - FAN MOTOR MOUNT 4 CWH55252J CWH55406J
6 PROPELLER FAN ASSY 1 CWH03K1020 CWH03K1010
7 NUT - PROPELLER FAN 1 CWH56053J ←
8 COMPRESSOR 1 5RS092XCE21 5RS092XCD21 O
9 ANTI-VIBRATION BUSHING 3 CWH50077 ←
10 NUT - COMPRESSOR MOUNT 3 CWH56000J ←
11 CONDENSER 1 CWB32C2789 CWB32C2810
12 CAPILLARY TUBE ASSY 1 CWB15K1229 CWB15K1279
13 DISCHARGE MUFFLER 1 CWB121010 ←
14 HOLDER COUPLING 1 CWH351047 CWH351023
15 2-WAYS VALVE (LIQUID) 1 CWB021421 CWB021449 O
16 3-WAY VALVE (GAS) 1 CWB011366 CWB011367 O
17 TERMINAL COVER 1 CWH171039A ←
18 NUT - TERMINAL COVER 1 CWH7080300J ←
19 SOUND PROOF BOARD 1 CWH151185 CWH151172
20 SOUND PROOF MATERIAL 1 CWG302478 CWG302436
21 SOUND PROOF MATERIAL 1 CWG302532 CWG302431
22 SENSOR CO - COMP TEMP 1 CWA50C2205 ← O
23 CONTROL BOARD COVER - TOP 1 CWH131324 CWH131264
24 ELECTRONIC CONTROLLER - MAIN 1 CWA73C5410R CWA73C5369R O
25 ELECTRONIC CONTROLLER - NF 1 CWH14C7640 - O
26 TERMINAL BOARD ASSY 1 CWA28K1036J ←
27 CABINET SIDE PLATE CO. 1 CWE04C1186 CWE04C1159
28 SENSOR CO - AIR TEMP AND PIPE TEMP 1 CWA50C2502 CWA50C2764 O
29 CABINET SIDE PLATE 1 CWE041110A CWE041248A
30 CABINET FRONT PLATE CO. 1 CWE06K1059 CWE06C1039
31 CABINET TOP PLATE 1 CWE031041A CWE031014A
32 PLATE - C. B. COVER TERMINAL 1 CWH131325 CWH131301
33 CONTROL BOARD COVER CO. 1 CWH13C1186 CWH13C1211
34 HANDLE 1 - CWE161010
35 STRAINER 1 CWB11025 ←
36 REACTOR 1 - G0C103J00029
37 WIRE NET 1 CWD041057A CWD041111A
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
To Next Page
