Panasonic CS-TZ20WKEW

212
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-TZ42WKEW CS-TZ50WKEW REMARK
1 CHASSIS COMPLETE 1 ACXD50C03410 
2 FAN MOTOR 1 L6CBYYYL0311  O
3 CROSS-FLOW FAN COMPLETE 1 ACXH02C01190 
4 BEARING ASSY 1 CWH64K1006 
5 SCREW - CROSS-FLOW FAN 1 CWH551146 
6 EVAPORATOR 1 ACXB30C29360 
7 FLARE NUT (LIQUID) 1 CWT251048 
8 FLARE NUT (GAS) 1 CWT251032 
9 LEVER ARM 1 ACXH65-00690 
10 CONTROL BOARD CASING 1 ACXH10-07900 
11 TERMINAL BOARD COMPLETE 1 ACXA28C06010 ACXA28C06080 O
12 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C60190 ACXA73C60200 O
13 ELECTRONIC CONTROLLER - INDICATOR 1 ACXA73-34540  O
14 INDICATOR HOLDER 1 ACXD93-20780 
15 SENSOR COMPLETE 1 CWA50C2664  O
16 ELECTRONIC CONTROLLER - WIFI 1 ACXA73-28520 
17 CONTROL BOARD COVER 1 ACXH13-08190 
18 CONTROL BOARD COVER 1 ACXH13-08200 
19 DISCHARGE GRILLE COMPLETE 1 ACXE20C05330 
20 BACK COVER CHASSIS 1 ACXD93-18680 
21 FULCRUM 1 ACXH62-00680 
22 VERTICAL VANE 2 ACXE24-03470 
23 SHAFT 2 ACXH63-01540 
24 SHAFT 2 ACXH63-01570 
25 HORIZONTAL VANE - INNER 1 ACXE24-03710 
26 HORIZONTAL VANE - OUTER 1 ACXE24-03720 
27 AIR SWING MOTOR 1 ACXA98-02000  O
28 CAP - DRAIN TRAY 1 CWH521259 
29 REMOTE CONTROL COMPLETE 1 ACXA75C18210  O
30 FRONT GRILLE COMPLETE 1 ACXE10C11870  O
31 INTAKE GRILLE COMPLETE 1 ACXE22C04140 
32 GRILLE DOOR COMPLETE 1 ACXE14C01340 
33 AIR FILTER 2 ACXD00-02860 
34 SCREW - FRONT GRILLE 3 XTT4+16CFJ  O
35 DRAIN HOSE 1 ACXH85-00200 
36 INSTALLATION PLATE 1 ACXH36-00650 
37 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 
38 AIR PURIFYING FILTER 1 CWD00C1293  O
39 OPERATING INSTRUCTION 1 ACXF55-27150 
40 OPERATING INSTRUCTION 1 ACXF55-27160 
41 OPERATING INSTRUCTION 1 ACXF55-27170 
42 OPERATING INSTRUCTION 1 ACXF55-27180 
43 OPERATING INSTRUCTION 1 ACXF55-27190 
44 INSTALLATION INSTRUCTION 1 ACXF60-38530 
45 INSTALLATION INSTRUCTION 1 ACXF60-38540 
46 INSTALLATION INSTRUCTION 1 ACXF60-38550 
47 INSTALLATION INSTRUCTION 1 ACXF60-38560 
48 INSTALLATION INSTRUCTION 1 ACXF60-38570 
49 INSTALLATION INSTRUCTION 1 ACXF60-38580 
50 INSTALLATION INSTRUCTION 1 ACXF60-38590 
51 INSTALLATION INSTRUCTION 1 ACXF60-38600 
52 INSTALLATION INSTRUCTION 1 ACXF60-38610 
