SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-RZ20WKE CU-RZ25WKE CU-RZ35WKE REMARK
1 CHASSIS COMPLETE 1 ACXD52K00150  CWD52K1399
2 SOUND PROOF MATERIAL (TOP) 1 CWG302737  CWG302719
3 FAN MOTOR BRACKET 1 CWD541157  
4 SCREW - FAN MOTOR BRACKET 2 CWH551217  
5 FAN MOTOR 1 L6CAYYYL0124   O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J  
7 PROPELLER FAN ASSY 1 CWH03K1100  
8 NUT - PROPELLER FAN 1 CWH56053J  
9 COMPRESSOR 1 9GS064XAA21 9GS075XAA21 9RS102XMA21 O
10 ANTI - VIBRATION BUSHING 3 CWH501038  CWH50077
11 NUT - COMPRESSOR MOUNT 3 CWH561096  
12 CONDENSER 1 ACXB32C14790 ACXB32C19940 ACXB32C15080
13 EXPANSION VALVE 1 ACXB05-01080  
14 DISCHARGE MUFFLER (4 W. VALVE) 2, 1
CWB121010
(QTY: 2)

CWB121010
(QTY: 1)
15 HOLDER COUPLING 1 CWH351233  
16 2-WAYS VALVE (LIQUID) 1 ACXB02-03380   O
17 3-WAY VALVE (GAS) 1 ACXB01-04540   O
19 REACTOR 1 G0C752J00004   O
20 TERMINAL COVER 1 CWH171041  CWH171039A
21 NUT - TERMINAL COVER 1 -  CWH7080300J
22 SOUND PROOF BOARD 1 CWH151427  
23 SOUND PROOF MATERIAL 1 ACXG30-10200  ACXG30-09370
24 SENSOR CO - COMP TEMP 1 CWA50C2830  CWA50C2205 O
25 CONTROL BOARD COVER - TOP 1 ACXH13-00450  
26 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C61780R ACXA73C61790R ACXA73C61800R O
27 TERMINAL BOARD ASSY 1 CWA28K1298   O
28 CABINET SIDE PLATE CO. 1 ACXE04C05610  ACXE04C00310
29
SENSOR CO - AIR TEMP AND PIPE
TEMP
1 CWA50C3079   O
30 CABINET SIDE PLATE 1 ACXE04-00130A  
31 CABINET FRONT PLATE CO. 1 CWE06C1563  CWE06C1566
32 CABINET TOP PLATE 1 CWE031230A  
33 PLATE - C. B. COVER TERMINAL 1 CWH131301  
34 CONTROL BOARD COVER CO. 1 CWH13C1359  
36 SOUND PROOF MATERIAL 1 -  CWG302316
38 4-WAYS VALVE 1 ACXB00-01290  ACXB00-01270 O
39 V-COIL COMPLETE (4-WAY VALVE) 1 ACXA43C00250  ACXA43C06380 O
40 O-RING 1 ACXB81-06510  
41 BAG - COMPLETE 1 CWG87C900  
42 V-COIL COMPLETE (EXP. VALVE) 1 ACXA43C06110   O
43 STRAINER 1 CWB11094  
44 DISCHARGE MUFFLER 1 CWB121021  
46 PANASONIC BADGE 1 CWE373439  
52 INSTALLATION INSTRUCTION 1 ACXF60-38420  
53 INSTALLATION INSTRUCTION 1 ACXF60-38430  
54 INSTALLATION INSTRUCTION 1 ACXF60-38440  
55 INSTALLATION INSTRUCTION 1 ACXF60-38450  
56 INSTALLATION INSTRUCTION 1 ACXF60-38460  
