(TZ20/25/35/42/50WK RZ20/25/35/50WK)
* The horizontal vane angle tolerance is within +/- 5 degree.
Side View (Inner Vane)
Closed
Position
Stopper
110º
Reference point
Step 1
Step 2
Step 3
Step 4
Step 5
Side View (Outer Vane)
Figure 2
115º
Closed
Position
Stopper
Reference point
Step 1
Step 2
Step 3
Step 4
Step 5
