171
19.1.1.3 To Remove Discharge Grille
Figure 6
19.1.1.4 To Remove Control Board
Figure 7
13. Remove the 2 screws of the
Discharge Grille.
15. Then pull the Discharge Grille downward
gently to dismantle it.
14. Pull out and remove the
Drain Hose from the
Discharge Grille.
16. Remove the 4 screws holding the
Control Board then pull out the
Control Board.
To Next Page
