Panasonic CS-TZ71ZKEW

223
SAFETY
REF.
NO.
PART NAME & DESCRIPTION QTY. CU-TZ20ZKE CU-TZ25ZKE CU-RZ25ZKE REMARK
1 BASE PAN ASSY 1 ACXD52K00150 ← ←
2 SOUND PROOF MATERIAL (COMP. TOP) 1 CWG302737 ← ←
3 FAN MOTOR BRACKET 1 CWD541157 ← ←
4 SCREW - FAN MOTOR BRACKET 2 ACXH55-07140 ← ←
5 FAN MOTOR 1 L6CAYYYL0155 ← ← O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J ← ←
7 PROPELLER FAN ASSY 1 CWH03K1100 ← ←
8 NUT - PROPELLER FAN 1 CWH56053J ← ←
9 COMPRESSOR 1 9GS075XCA21 ← ← O
10 ANTI - VIBRATION BUSHING 3 ACXH50-00140 ← ←
11 NUT - COMPRESSOR MOUNT 3 CWH561096 ← ←
12 CONDENSER 1 ACXB32C26830 ACXB32C26840 ← O
13 EXPANSION VALVE 1 ACXB05-01260 ← ←
14 DISCHARGE MUFFLER(4 W.VALVE) 2 CWB121010 ← ←
15 HOLDER COUPLING 1 CWH351233 ← ←
16 2-WAYS VALVE (LIQUID) 1 ACXB02-03370 ← ← O
17 3-WAY VALVE (GAS) 1 ACXB01-04540 ← ← O
19 REACTOR 1 G0C392J00028 ← ← O
20 TERMINAL COVER 1 CWH171041 ← ←
22 SOUND PROOF BOARD 1 CWH151427 ← ←
23
SOUND PROOF MATERIAL - COMP.
BODY
1 ACXG30-11530 ← ←
24 SENSOR CO-COMP TEMP 1 ACXA50C17680 ← ← O
25 CONTROL BOARD COVER-TOP 1 ACXH13-00450 ← ←
26 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C94840R ACXA73C94850R ← O
27 TERMINAL BOARD ASSY 1 CWA28K1298 ← ← O
28 CABINET SIDE PLATE CO. 1 ACXE04C05590 ← ←
29 SENSOR CO-AIR TEMP AND PIPE TEMP 1 CWA50C3267 ← ← O
30 CABINET SIDE PLATE 1 ACXE04-00130A ← ←
31 CABINET FRONT PLATE CO. 1 CWE06C1563 ← ←
32 CABINET TOP PLATE 1 CWE031230A ← ←
33 PLATE - C. B. COVER TERMINAL 1 CWH131301 ← ←
34 CONTROL BOARD COVER CO. 1 CWH13C1359 ← ←
36 SOUND PROOF MATERIAL - CABINET 1 ACXG30-13980 ← ←
38 4-WAYS VALVE 1 ACXB00-01290 ← ← O
39 V-COIL COMPLETE - 4-WAY VALVE 1 ACXA43C00250 ← ← O
40 O-RING 1 ACXB81-06510 ← ←
41 ACCESSORY-COMPLETE 1 ACXH82C21740 ← ←
42 V-COIL COMPLETE - EXP.VALVE 1 ACXA43C06110 ← ← O
43 STRAINER 1 CWB11094 ← ←
44 DISCHARGE MUFFLER 1 CWB121021 ← ←
46 PANASONIC BADGE 1 CWE373439 ← ←
47 TUBE ASSY COMPLETE 1 ACXT00C44260 ACXT00C43660 ←
48 TUBE ASSY COMPLETE- 4 WAYS 1 ACXT00C44270 ACXT00C44280 ←
49 PLATE SPRING 1 CWH71044 ← ←
50 CONTROL BOARD CASING 1 ACXH10-00750 ← ←
51 DISCHARGE GRILLE 1 CWE201306 ← ←
