SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-UE9RKE CU-UE12RKE REMARK
1 CHASSIS ASSY 1 CWD50K2073 ←
2 SOUND PROOF MATERIAL 1 CWG302314 ←
3 FAN MOTOR BRACKET 1 CWD541089 ←
4 SCREW - FAN MOTOR BRACKET 2 CWH551217 ←
5 FAN MOTOR 1 ARS6411AC ← O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J ←
7 PROPELLER FAN ASSY 1 CWH03K1010 ←
8 NUT - PROPELLER FAN 1 CWH56053J ←
9 COMPRESSOR 1 5RS092XCD21 5RS102XBC21 O
10 ANTI - VIBRATION BUSHING 3 CWH50077 ←
11 NUT - COMPRESSOR MOUNT 3 CWH561096 ←
12 CONDENSER 1 CWB32C2985 CWB32C2448
13 TUBE ASS’Y (CAP. & CHECK VALVE) 1 CWT01C7081 CWT01C7082 O
14 DISCHARGE MUFFLER (4-WAY VALVE) 1 CWB121010 ← O
15 HOLDER COUPLING 1 CWH351233 ←
16 2-WAYS VALVE (LIQUID) 1 CWB021559 CWB021457 O
17 3-WAY VALVE (GAS) 1 CWB011374 ← O
19 REACTOR 1 G0C103J00013 ← O
20 TERMINAL COVER 1 CWH171039A ←
21 NUT - TERMINAL COVER 1 CWH7080300J ←
22 SOUND PROOF BOARD 1 CWH151172 ←
23A SOUND PROOF MATERIAL 1 CWG302948 ←
23B SOUND PROOF MATERIAL 1 CWG302316 ←
23C SOUND PROOF MATERIAL 1 CWG302317 ←
24 SENSOR CO - COMP TEMP 1 CWA50C2632 ← O
25 CONTROL BOARD COVER - TOP 1 CWH131264 ←
26 ELECTRONIC CONTROLLER - MAIN 1 CWA73C9001R CWA73C9002R O
27 TERMINAL BOARD ASSY 1 CWA28K1036J ← O
28 CABINET SIDE PLATE CO. (RIGHT) 1 CWE04C1512 ←
29 SENSOR CO - AIR TEMP AND PIPE TEMP 1 CWA50C2767 ← O
30 CABINET SIDE PLATE 1 CWE041031A ←
31 CABINET FRONT PLATE CO. 1 CWE06C1039 CWE06C1136
32 CABINET TOP PLATE 1 CWE031014A ←
33 PLATE - C. B. COVER TERMINAL 1 CWH131301 ←
34 CONTROL BOARD COVER CO. 1 CWH13C1211 ←
35 HANDLE 1 CWE161010 ←
38 4-WAYS VALVE 1 CWB001063 ← O
39 V-COIL COMPLETE (4-WAY VALVE) 1 CWA43C2431 ← O
42 FLEXIBLE PIPE (L-TUBE) 1 CWH5850080 ←
43 PACKING - L.TUBE 1 CWB81012 ←
50 ACCESSORY CO. (DRAIN ELBOW) 1 CWG87C900 ←
51 BAG 1 CWG861078 ←
52 BASE BOARD - COMPLETE 1 CWG62C1095 ←
53 SHOCK ABSORBER (RIGHT) 1 CWG712969 ←
54 SHOCK ABSORBER (LEFT) 1 CWG712970 ←
55 C.C.CASE 1 CWG568356 ←
(Note)
 All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).
 “O” marked parts are recommended to be kept in stock.
