Panasonic CS-UE9RKE

16
5. Dimensions
5.1 Indoor Unit & Remote Control
5.1.1 CS-PE9RKE CS-PE12RKE CS-UE9RKE CS-UE12RKE
<Bottom View>
<Front View>
<Top View>
<Rear View>
Air intake
direction
<Side View> <Side View>
Air outlet
direction
Left piping
hole
<Remote Control>
<Remote Control Holder>
2247
134
61
51
870
1~2 1~2
214
61
45
Right piping
hole
290
214
125 115
60 60
410 (41 ~ 61)
Gas side
Liquid side
Relative position between the indoor unit and the installation plate <Front View>
Right
piping
hole
Left
piping
hole
497.2
Indoor unit
external
dimensions
line
Installation
plate
Unit : mm
16.5
264.2
128
439 432
128
43
95
241.5 241.5
128
