Panasonic CS-UE9RKE Service Manual

6
Model
Indoor CS-PE9RKE CS-PE12RKE
Outdoor CU-PE9RKE CU-PE12RKE
Compressor
Type Hermetic Motor / Rotary Hermetic Motor / Rotary
Motor Type Brushless (6-poles) Brushless (6-poles)
Output Power W 650 700
Indoor Fan
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type DC / Transistor (8 poles) DC / Transistor (8 poles)
Input Power W 47.3 47.3
Output Power W 40.0 40.0
Speed
QLo
Cool rpm 560 610
Heat rpm 690 780
Lo
Cool rpm 680 800
Heat rpm 760 980
Me
Cool rpm 890 990
Heat rpm 980 1140
Hi
Cool rpm 1110 1190
Heat rpm 1200 1300
SHi
Cool rpm 1160 1240
Heat rpm 1250 1300
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC / Transistor (8 poles) DC / Transistor (8 poles)
Input Power W – –
Output Power W 40 40
Speed Hi
Cool rpm 770 800
Heat rpm 750 800
Moisture Removal L/h (Pt/h) 1.5 (3.2) 2.0 (4.2)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min) 5.26 (186) 5.85 (207)
Heat m
3
/min (ft
3
/min) 6.80 (240) 7.51 (265)
Lo
Cool m
3
/min (ft
3
/min) 6.68 (236) 8.10 (286)
Heat m
3
/min (ft
3
/min) 7.62 (269) 9.98 (352)
Me
Cool m
3
/min (ft
3
/min) 9.22 (326) 10.40 (367)
Heat m
3
/min (ft
3
/min) 10.22 (361) 11.70 (413)
Hi
Cool m
3
/min (ft
3
/min) 11.7 (415) 12.7 (450)
Heat m
3
/min (ft
3
/min) 12.8 (450) 13.4 (475)
SHi
Cool m
3
/min (ft
3
/min) 12.34 (436) 13.29 (469)
Heat m
3
/min (ft
3
/min) 13.41 (474) 14.00 (494)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 32.1 (1135) 31.0 (1095)
Heat m
3
/min (ft
3
/min) 31.2 (1100) 31.0 (1095)
Refrigeration
Cycle
Control Device Check Valve & Cap. Tube Check Valve & Cap. Tube
Refrigerant Oil cm
3
FV50S (320) FV50S (320)
Refrigerant Type g (oz) R410A, 850 (30.0) R410A, 950 (33.5)
Dimension
Height (I/D / O/D) mm (inch) 290 (11-7/16) / 542 (21-11/32) 290 (11-7/16) / 542 (21-11/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 780 (30-23/32) 870 (34-9/32) / 780 (30-23/32)
Depth (I/D / O/D) mm (inch) 214 (8-7/16) / 289 (11-13/32) 214 (8-7/16) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 31 (68) 9 (20) / 33 (73)
