94
16.1.1.5 To remove control board
12. Remove 4 screws holding the
control board then pull out the
control board.
Figure 6
16.1.1.6 To remove cross flow fan and indoor fan motor
13. Remove the screw that holding
the cross flow fan and fan motor
axis.
Figure 7
16.
14.
15.
Figure 8
To Next Page
