Panasonic CS-W18CKE User Manual

Unit CS-W24CKE CU-W24CKE
Power Source Phase, Voltage, Cycle Single, 230, 50 Hz
Cooling Capacity kW (BTU/h) 7.03 (24,000)
Heating Capacity kW (BTU/h) 7.72 (26,300)
Moisture Removal l/h (Pint/h) 4.0 (8.5)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m
3
/min (cfm) Cooling; 14.4 (510)
Heating; 15.6 (550)
27.4 (970)
Indoor Air (Me) m
3
/min (cfm) Cooling; 16.4 (580)
Heating; 16.4 (580)
—
Indoor Air (Hi) m
3
/min (cfm) Cooling; 17.5 (620)
Heating; 18.1 (640)
47.2 (1,670)
Indoor Air (SHi) m
3
/min (cfm) Cooling; 18.1 (640)
Heating; 18.1 (640)
—
Noise Level dB (A) Cooling; High 47, Low 41
Heating; High 46, Low 41
Cooling; High 60
Heating; High 61
Power level dB Cooling; 59
Heating; 57
Coolling; 74
Heating; 74
Electrical Data Input Power kW Cooling; 2.78
Heating; 2.69
Running Current A Cooling; 13.1
Heating; 12.9
EER W/W (BTU/hW) Cooling; 2.53 (8.63)
COP W/W (BTU/hW) Heating; 2.87 (9.79)
Starting Current A 65.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 5/8”
L ; Half Union 1/4”
G ; 3-way valve 5/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 5/8”
L ; (liquid side) 1/4”
G ; (gas side) 5/8”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (2.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 26 - 31/32 (685)
Width inch (mm) 39 - 9/32 (998) 31 - 1/2 (800)
Depth inch (mm) 8 - 9/32 (210) 11 - 13/16 (300)
Net Weight lb (kg) 24 (11.0) 135 (61.0)
Compressor Type — Rotary (1 cylinder) rolling piston
type
Motor Type — Induction (2-poles)
Rated Output kW — 2.2
8
CS-W18CKE CU-W18CKE / CS-W24CKE CU-W24CKE
