3 SPECIFICATION (HEAT PUMP TYPE )
3.1. CS-W34BB4P / CU-W34BBP5
ITEM / MODEL Indoor Unit Outdoor unit
Main Body CS-W34BB4P CU-W34BBP5
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL51P (Wireless)
Cooling Capacity kW 10.0
BTU/h 34,100
Heating Capacity kW 11.2
BTU/h 38,200
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min 23
cfm 812
Outside Dimension (H x W x D) mm 290 x 840 x 840 1220 x 900 x 320
inch 11-7/16 x 33-1/24 x 33-1/24 48-1/24 x 35-7/16 x 12-19/32
Net Weight kg 30 97
lbs 66 214
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 32 I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic-1 (Rotary), 1
Starting Method - Direct on-line starting
Motor Type - 2-pole 1-phase induction motor
Rated Output kW - 3.0
Fan Type, Number of Set Turbo fan Propeller fan
Motor Type 6-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.05 0.05 x 2
Air-heat Exchanger Slit-fin type X-Louvre-fin type
Refrigerant Control Cool Capillary tube -
Heat - Capillary tube
Refrigerant Oil (Charged) litre - MMMAPOE (1.2)
Refrigerant (Charged) kg - R407C (3.2)
(oz) (113)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal thermostat for fan motor,
Crankcase heater, High and heating pressure switch, Current transformer
Noise Level dB (A) Hi 45 Lo 41 Cooling 56, Heating 58
Power level dB Cooling : Hi 60 Lo 56
Heating : Hi 60 Lo 56
Cooling 69, Heating 71
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50Hz)
ITEM / MODEL CS-W34BB4P, CU-W34BBP5
Condition by JIS B 8615
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cool 3.88 3.88 3.88
Heat 4.07 4.07 4.07
Running Current A Cool 18.6 18.7 18.8
Heat 18.7 18.8 18.9
Starting Current A 94 99 103
Power Factor % Cool 95 90 86
Heat 99 94 90
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V 50Hz
