14 COMPONENT SPECIFICATION
Compressor
Models Heat pump model 50Hz CU-W34BBP5
Cooling only model 50Hz CU-V34BBP5
Compressor Model single-phase -
3-phase -
Compressor Type ROTARY
No. of Cylinders 1
Revolution r/min 2,900
Piston Diplacement m
3
/h 11.39
Motor
Type
Starting Method Direct on-line Starting
Rated Output kW 3.0
Poles 2
Insulation Class E
Oil Type MMMAPOE
Charge L 1.3
Evaporator
Models CS-W34BB4P
Tube Material Copper tube
Outer Diameter mm 7.0
Thickness mm 0.27
Row 2
No. of Tubes/Row 12
Fin Material Aluminium
Thickness mm 0.105
Fin Pitch NO./inch 19
Fin Surface Z Slit fin
Total Face Area m
2
0.456
Fan Type Turbo fan
No. of /Unit 1
Fan
Motor
Starting Method Direct on-line Starting
Rated Output kW 0.05
Poles 6
Phase Single-Phase
Insulation Class E
Condenser
Models Heat pump model CU-W34BBP5
Cooling only model CU-V34BBP5
Tube Material Copper tube
Outer Diameter mm 9.52
Thickness mm 0.3
Row 2
No. of Tubes/Row 46
Fin Material Aluminium
Thickness mm 0.105
Fin Pitch NO./inch 14
Fin Surface X-Louvre fin
Total Face Area m
2
0.82
Fan Type Propeller Fan
No.of /Unit 2
Fan Starting Method Direct on-line Starting
Motor Rated Output kW 0.055 x 2
Poles 6
Phase Single-Phase
Insulation Class E
