4 SPECIFICATION (COOLING ONLY TYPE )
4.1. CS-W34BB4P / CU-V34BBP5
ITEM / MODEL Indoor Unit Outdoor unit
Main Body CS-W34BB4P CU-V34BBP5
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL01P (Wireless)
Cooling Capacity kW 10.0
BTU/h 34,100
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min 23
cfm 812
Outside Dimension (H x W x D) mm 290 x 840 x 840 1220 x 900 x 320
inch 11-7/16 x 33-1/24 x 33-1/24 48-1/24 x 35-7/16 x 12-19/32
Net Weight kg 30 95
lbs 66 209
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic-1 (Rotary), 1
Starting Method - Direct on-line starting
Motor Type - 2-pole 1-phase induction motor
Rated Output kW - 3.0
Fan Type, Number of Set Turbo fan Propeller fan
Motor Type 6-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.05 0.05 x 2
Air-heat Exchanger Slit-fin type X-Louvre-fin type
Refrigerant Control Capillary tube Capillary tube
Refrigerant Oil (Charged) litre - MMMAPOE (1.3)
Refrigerant (Charged) kg - R407C (3.2)
(oz) (113)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal thermostat for fan motor,
Crankcase heater, High pressure switch, Current transformer
Noise Level dB (A) Hi 45 Lo 41 56
Power level dB Hi 60 Lo 56 69
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ELECTRICAL DATA (50Hz)
ITEM / MODEL CS-W34BB4P, CU-V34BBP5
Condition by JIS B 8615
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cool 3.88 3.88 3.88
Running Current A Cool 18.6 18.7 18.8
Starting Current A 94 99 103
Power Factor % Cool 95 90 86
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V 50Hz
