13 SAFETY DEVICE
INDOOR UNIT
Heat pump model
Indoor unit CS-W34BB4P
Cooling only model
For Fan Motor Protection, OFF °C 135
Internal Protector (49F) ON °C 85
For Control Protection, Fuse CUT A 3.15
OUTDOOR UNIT
Outdoor Unit Heat pump model 50Hz CU-W34BBP5
Cooling only model 50Hz CU-V34BBP5
For Refrigerant Cycle, OFF MPa
(*1)
3.1
High Pressure Switch (63H
1
) ON MPa
(*1)
2.3
For OFF A 11
Compressor (Heat pump)
Over Current OFF A 11
Protection (Cooling only model) 50Hz
RESET - Automatic
Discharge Temp. Protection, Compressor °C 120
Discharge Temp. OFF
Thermistor (Th1)
Liquid Compression Protection, Crankcase
Heater
Input power W 34~41
Compressor OFF °C 145
Protection, 50Hz
Internal Protector ON °C
50Hz
61
Trip time 50Hz 3-10sec/37A
For Fan Motor Protection, OFF °C 135
Internal Protector (49F) ON °C 85
Heating Pressure Switch (Heat OFF MPa
(*1)
2.35
Pump Only) (Fan Speed) (63H
2
) ON MPa
(*2)
1.96
Cooling Control, Control method Th 30°C ----- High speed
Heat Exchanger Th < 30°C ------5 speed step control
Outlet Temp. Thermistor (Th2)
For Control Protection, Fuse CUT A 6.3
(*1) MPa = 10.2 kgf/cm
2
(*2) Head Thermostat only for CU-A28BBP8 / CU-C28BBP8
