NO. PART DESCRIPTION QTY CS-W34BB4P
1 BASE PAN ASS’Y 1 CWD52K1034
2 INNER POLYSTYRENE (TOP) 1 CWG071057
3 INNER POLYSTYRENE (SIDE) 1 CWG07C1017
4 CABINET SIDE PLATE ASS’Y 1 CWE04K1003
5 CABINET SIDE PLATE ASS’Y 1 CWE04K1004
6 FAN MOTOR 1 CWA921050
7 ANTI-VIBRATION BUSHING 4 CWH501016
8 SCREW-FAN MOTOR 4 CWH551032
9 CORD HOLDER 1 CWD74K1001
10 TURBO FAN 1 CWH03K1003
10a NUT for TURBO FAN 1 XNG8
10b SP WASHER 1 XWA8
10c WASHER 1 CWH571008
11 EVAPORATOR 1 CWB30C1196
11a EVAPORATOR SUPPORTER 1 CWD911116
11b EVAPORATOR HOLDER 1 CWD911137
11c EVAPORATOR HOLDER 1 CWD911127
11d TUBE ASS’Y (CAPIL. TUBE-EVA) 1 -
12 HEATPROOF TUBE (24) 1 CWG021023
12a HEATPROOF TUBE 1 CWG021021
13 ”FLARE NUT (3/8”)/(1/4”) 1 CWT25005 (3/8”)
13a ”FLARE NUT (6/8”)/(5/8”) 1 -
14 PIPE COVER 1 CWD93C1020
15 SENSOR-EVAPORATOR 1 CWA501047
16 SPRING FOR SENSOR 1 CWH711010
17 DRAIN PUMP COMPLETE 1 CWB53C1004
18 PANEL DRAIN PUMP ASS’Y 1 CWD93K1005
19 DRAIN PUMP 1 CWB532005
20 ANTI-VIBRATION BUSHING 3 CWH501017
21 FLOAT SWITCH - DRAIN PUMP 1 CWA121076
22 DRAIN NOZZLE 1 CWH411005
23 FLEXIBLE PIPE 1 CWH851030
24 DRAIN HOSE HEAT INSULATION 1 CWG101025
25 DRAIN PAN-COMPLETE 1 CWH40C1019
26 DRAIN PLUG 1 CWB82018
27 NOISE FILTER 1 CWA491018
28 ELECTRONIC CONTROLLER 1 CWA73C1166
29 SPACER 6 CWH541028
30 TRANSFORMER 1 CWA401028
31 CAPACITOR-FAN MOTOR (MF/V) 1 DS461135QP-A (1.3/460)
32 CONTROL BOARD 1 CWH141005
33 HOLDER-TERMINAL BOARD 1 CWD932155
34 TERMINAL BOARD 1 CWA281015
35 LEADWIRE-FUSE&SENSOR 1 CWA67C3691
36 CONTROL BOARD COVER[CAUTION] 1 CWH13C1042
37 CONT. BOARD COVER-WIRING DIAG. 1 CWH13C1043
38 AIR GUIDER BLOWER WHEEL 1 CWD321031
39 ACCESSORY COMPLETE 1 CWH82C1107
40 WIRED REMOTE CONTROL COMPLETE 1 -
41 WIRELESS R/CONTROL COMP. (HP) 1 -
41 WIRELESS R/CONTROL COMP. (C) 1 -
42 RAY RECEIVER (HEAT PUMP MODEL) 1 -
42 RAY RECEIVER (COOLING ONLY) 1 -
OPERATING INSTRUCTION 1 CWF563597
INSTALLATION INSTRUCTION 1 CWF612268
All parts are supplied from MACC, Malaysia (Vendor Code: 086)
105
