4 SPECIFICATION (COOLING ONLY TYPE )
CS-W50BTP / CU-V50BBP8
ITEM / MODEL Indoor Unit Outdoor unit
Main Body CS-W50BTP CU-V50BBP8
Remote CZ-RD51P (Wired)
Control CZ-RL01P (Wireless)
Cooling Capacity kW 14.0
BTU/h 47,700
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min 35
cfm 1236
Outside Dimension (H x W x D) mm 250 x 1600 x 700 1220 x 1100 x 320
inch 9-27/32 x 62-31/32 x 27-9/16 48-1/24 x 43-5/16 x 12-19/32
Net Weight kg 47 112
lbs 104 247
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic-1 (Scroll), 1
Starting Method - Direct on-line starting
Motor Type - 2-pole 3-phase induction motor
Rated Output kW - 4.10
Fan Type, Number of Set Sirocco fan Propeller fan
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.14 0.055 x 2
Air-heat Exchanger Slit-fin type X-Louvre-fin type
Refrigerant Control Capillary tube Capillary tube
Refrigerant Oil (Charged) litre - MMMAPOE
Refrigerant (Charged) kg - R407C (4.4)
(oz) (155)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal thermostat for fan motor,
Crankcase heater, High pressure switch, Current transformer
Noise Level dB (A) Hi 49 Lo 45 56
Power level dB Hi 66 Lo 62 69
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ELECTRICAL DATA (50Hz)
ITEM / MODEL CS-W50BTP, CU-V50BBP8
Condition by JIS B 8615
Volts V 380 400 415
Phase 3N 3N 3N
Power Consumption kW Cool 5.35 5.35 5.35
Running Current A Cool 9.2 9.2 9.2
Starting Current A 69 69 69
Power Factor % Cool 88 84 81
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3N~380V, 400V, 415V 50Hz
10
