9 OPERATION RANGE
Power Supply
The applicable voltage range for each unit is given in the following table. The working voltage among the three phases must be
balanced within a 3% deviation from each voltage at the compressor terminals. The starting voltage must be higher than 85% of
the rated voltage.
Power Supply
MODEL Unit Main Power Applicable Voltage
CU- Phase, Volts Hz Max Min
V50BBP8 3N~380 50 418 342
W50BBP8 3N~400 50 440 360
3N~415 50 457 374
Indoor and Outdoor Temperature
•
• •
•
Cooling only type
Model 50Hz CU-V50BBP8
Operating Hz Indoor Temp. (D.B./W.B.) (°C) Outdoor Temp. (D.B./W.B.) (°C)
Max Min Max Min
Cooling 50 32/23 21/15 43/- -5/-
•
• •
•
Heat pump type
Model 50Hz CU-W50BBP8
Operating Hz Indoor Temp. (D.B./W.B.) (°C) Outdoor Temp. (D.B./W.B.) (°C)
Max Min Max Min
Cooling 50 32/23 21/15 43/- -5/-
Heating 50 27/- 16/- 24/18 -10/-
28
