Panasonic CS-W50BD3P Service Manual

15.2. COOLING PERFORMANCE
CS-W50BTP
Model Cooling capacities are based on conditions below.
CS-W50BTP Cooling
capacity 14.0 kW
O 1 phase, 50Hz, 230V
O Indoor temperature 27°C D.B.T. 19°C W.B.T.
O Outdoor temperature 35°C D.B.T.
O Standard air volume 35m
3
/min
Cooling capacity
Indoor Outdoor Temperature (°C D.B.T.)
Air 25 30 35 40 43
Temperature TC TC TC TC TC
D.B. W.B. kW kW kW kW kW
17 14.57 14.00 13.17 12.18 11.47
23 19 15.39 14.91 14.15 13.19 12.52
22 16.81 16.36 15.61 14.60 13.91
17 14.40 13.84 13.04 12.09 11.41
25 19 15.41 14.88 14.07 13.11 12.42
22 16.80 16.29 15.49 14.43 13.78
17 14.22 13.68 12.91 12.00 11.36
27 19 15.43 14.84 14.00 13.02 12.32
22 16.79 16.22 15.37 14.28 13.65
17 14.19 13.68 12.88 12.10 11.50
29 19 15.40 14.84 14.01 13.12 12.47
22 16.72 16.15 15.27 14.30 13.64
17 14.17 13.69 11.97 12.16 11.59
32 19 15.37 14.84 14.01 13.19 12.57
22 16.67 16.10 15.26 14.31 13.64
Cooling power consumption
Indoor Outdoor Temperature (°C D.B.T.)
Air 25 30 35 40 43
Temperature IPT IPT IPT IPT IPT
D.B. W.B. kW kW kW kW kW
17 4.26 4.61 5.02 5.51 5.84
23 19 4.51 4.89 5.33 5.84 6.19
22 4.88 5.28 5.75 6.31 6.69
17 4.26 4.61 5.01 5.48 5.80
25 19 4.54 4.90 5.34 5.83 6.18
22 4.90 5.29 5.76 6.29 6.67
17 4.27 4.60 5.01 5.44 5.77
27 19 4.56 4.92 6.35 5.82 6.16
22 4.93 5.31 5.78 6.28 6.66
17 4.24 4.59 4.95 5.31 5.54
29 19 4.53 4.91 5.29 5.68 5.92
22 5.00 5.40 5.82 6.25 6.51
17 4.23 4.58 4.91 5.23 5.38
32 19 4.52 4.90 5.24 5.58 5.75
22 5.04 5.47 5.85 6.23 6.57
