Panasonic CS-W50BD3P Service Manual

14 COMPONENT SPECIFICATION
Compressor
Model Heat pump model 50Hz CU-W50BBP8
Cooling only 50Hz CU-V50BBP8
model
60Hz -
Compressor Model single-phase -
3-phase ZR68KCE-TFD
Compressor Type SCROLL
No. of Cylinders 1
Revolution r/min 2,900
Piston Displacement m
3
/h 16.18
Motor Type Starting Method Direct on-line Starting
Rated Output kW 4.1
Poles 2
Insulation Class E
Oil Type MMMAPOE
Charge L 1.8
Evaporator
Models CS-W50BTP
Tube Material Copper tube
Outer Diameter mm 7.0
Thickness mm 0.27
Row 3
No. of Tubes/Row 12
Fin Material Aluminium
Thickness mm 0.105
Fin Pitch NO./inch 19
Fin Surface Z Slit fin
Total Face Area m
2
0.464
Fan Type Sirocco fan
No. of /Unit 4
Fan Motor Starting Method Direct on-line Starting
Rated Output kW 0.14
Poles 4
Phase Single-Phase
Insulation Class E
Condenser
Models Heat pump CU-W50BBP8
model
Cooling only model CU-V50BBP8
Tube Material Copper tube
Outer Diameter mm 9.52
Thickness mm 0.3
Row 2
No. of Tubes/Row 46
Fin Material Aluminium
Thickness mm 0.105
Fin Pitch NO./inch 14
Fin Surface X-Louvre fin
Total Face Area m
2
1.05
Fan Type Propeller Fan
No. of /Unit 2
Fan Starting Method Direct on-line Starting
Motor Rated Output kW 0.055 x 2
Poles 6
Phase Single-Phase
Insulation Class E
34
