Panasonic CS-W50BD3P Service Manual

11 OPERATING CHARACTERISTIC
HEAT PUMP MODEL
Model Main Power Source Compressor Motor Indoor Unit
Fan Motor
Outdoor unit
Fan Motor
Electrical Data (50Hz)
Voltage Frequency S.C. R.C. (A) IPT (kW) R.C. IPT R.C. IPT F.C.(A) IPT(kW)
(v) (Hz) (A) Cool/Heat Cool/Heat (A) (kW) (A) (kW) Cool/Heat Cool/Heat
HEAT CS-W50BTP 380 50 69 8.62 / 8.62 4.97 / 5.07 0.74 0.16 0.99 0.22 9.20 / 9.20 5.35 / 5.45
PUMP CU-W50BBP8 400 50 69 8.62 / 8.62 4.95 / 5.05 0.73 0.17 1.02 0.23 9.20 / 9.20 5.35 / 5.45
MODEL 415 50 69 8.61 / 8.61 4.93 / 5.03 0.73 0.17 1.04 0.25 9.20 / 9.20 5.35 / 5.45
COOLING ONLY MODEL
Model Main Power Source Compressor Motor Indoor Unit Fan
Motor
Outdoor unit Fan
Motor
Electrical Data (50Hz)
Voltage Frequency S.C. R.C. (A) IPT (kW) R.C. IPT R.C. IPT F.C.(A) IPT(kW)
(v) (Hz) (A) Cool Cool (A) (kW) (A) (kW) Cool Cool
COOLING CS-W50BTP 380 50 69 8.62 4.97 0.74 0.16 0.99 0.22 9.20 5.35
ONLY CU-V50BBP8 400 50 69 8.62 4.95 0.73 0.17 1.02 0.23 9.20 5.35
MODEL 415 50 69 8.61 4.93 0.73 0.17 1.04 0.25 9.20 5.35
Legend : S.C. = Starting Current, R.C. = Running Current, IPT = Power Consumption
31
