EnglishSafety precautions / System Overview
System Overview
• Requires the APP to work with a smartphone with Android 4.4 and above, or iOS 9 and
above.
However, there is no guarantee that the APP will work well with all Android OS version.
• The Network Adaptor is designed specifi cally as a terminal for “Panasonic Comfort Cloud”
app.
• The Wireless LAN network coverage must reach the air conditioner installation location.
Network Adaptor Wireless LAN Module (built-in)
Model DNSK-P11
Input Voltage DC 5V (From Air Conditioner Indoor Unit)
Current Consumption Tx/Rx max. 290/100 mA
Wireless LAN standard IEEE 802.11 b/g/n
Frequency range 2.4 GHz band
Encryption WPA2-PSK (TKIP/AES)
Specifi cation
Maximum radio-frequency power transmitted in the frequency bands
Type of wireless Frequency band Max. EIRP (dBm)
WLAN 2412 - 2472 MHz 20 dBm
• Do NOT disassemble or alter this Network Adaptor in any way.
• Do NOT remove this Network Adaptor from the appliance product during operations.
• Data transmitted and received over radio waves may be intercepted and monitored.
Precaution
Download from app store
Network
Adaptor
Router
Internet
Smartphone
Items you need to prepare
(purchase and subscribe separately)
Panasonic Comfort Cloud
app (free)
Indoor Unit
To Next Page
