43
Français
Table des matières
Consignes de sécurité ...... 44-56
Présentation du système ....... 57
Consignes d’utilisation ..... 58-67
Q & R sur l’adaptateur réseau
.. 68-69
Pour en savoir plus ................ 70
Instructions de nettoyage ...... 71
Dépannage ....................... 72-74
Informations ..................... 75-77
B
Fonctionnement de base
2
Appuyez sur
MODE
pour sélectionner le
mode souhaité.
DRY
AUTO HEAT
COOL
1
Appuyez sur
pour mettre le
fonctionnement en
marche/arrêt.
POWER
Veuillez noter que
l’indication se
trouve sur l’af cheur
pour démarrer l’unité.
3
Sélectionnez la
température souhaitée.
Haut
Bas
Plage de sélection :
16,0 °C ~ 30,0 °C /
60 °F ~ 86 °F.
Maintenez la touche
enfoncée pendant environ 10
secondes passer l’indication de
température en °C ou en °F.
Nous vous remercions d’avoir
porté votre choix sur un climatiseur
Panasonic.
Les illustrations de ce mode d’emploi
sont fournies à titre d’exemple
uniquement et peuvent présenter des
différences par rapport à l’appareil
proprement dit. Celui-ci peut être modi é
sans préavis à des ns d’amélioration.
Accessoires
• Télécommande
Piles AAA ou R03 × 2
Support de la télécommande
Vis pour le support de la
télécommande × 2

Other manuals for Panasonic CS-Z20VKEW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic CS-Z20VKEW and is the answer not in the manual?

Panasonic CS-Z20VKEW Specifications

General IconGeneral
TypeSplit system
Multi-splitNo
Product colorWhite
Gas hose diameter12.7 mm
Hose length (max)15 m
Hose length (min)3 m
Inverter technologyYes
Liquid hose diameter6.35 mm
Refrigerating mediumR32
Dehumidifying capacity1.3 l/h
Air conditioner functionsCooling, Dehumidifying, Heating
Refrigerating medium weight700 g
Cooling capacity in watts (max)2400 W
Cooling capacity in watts (min)750 W
Heating capacity in watts (max)4000 W
Heating capacity in watts (min)700 W
Cooling capacity in watts (nominal)2050 W
Operating temperature (cooling) (T-T)-10 - 43 °C
Operating temperature (heating) (T-T)-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)7.5
Heating capacity in watts (nominal) (Colder heating season)- W
Heating capacity in watts (nominal) (Average heating season)2800 W
Seasonal efficiency rating (heating) (SCOP) (Warmer heating season)-
Seasonal efficiency rating (heating) (SCOP) (Average heating season)4.7
AC input voltage230 V
AC input frequency50 Hz
Design load (cooling)2.05 kW
Energy efficiency scaleA+++ to D
Energy efficiency class (cooling)A++
Annual energy consumption (cooling)98 kWh
Design load (heating) (Warmer heating season)- kW
Design load (heating) (Average heating season)2.8 kW
Annual energy consumption (heating) (Colder heating season)- kWh
Annual energy consumption (heating) (Average heating season)626 kWh
Outdoor unit depth289 mm
Outdoor unit width780 mm
Outdoor unit height542 mm
Outdoor unit weight27000 g
Outdoor units quantity1
Outdoor unit noise level46 dB
Cooling airflow (outdoor unit)1614 m³/h
Heating airflow (outdoor unit)1446 m³/h
Indoor unit typeWall-mountable
Indoor unit depth194 mm
Indoor unit width919 mm
Indoor unit height295 mm
Indoor unit weight9000 g
Cooling airflow (indoor unit)594 m³/h
Heating airflow (indoor unit)642 m³/h
Indoor unit noise level (low speed)19 dB
Indoor unit noise level (high speed)37 dB
