Panasonic CS-Z35UFEAW - Remove the Indoor Unit Front Grille

124
19.2 Remove the Front Grille
2. Take out the Front Vane.
Slide the hook to left side.
1. Release the hook in the right side of the
Top Vane and then take out the Top Vane.
Top Vane
Front Vane
3. Release the 2 screws to
take out of the Front Grille.
Front Grille
