127
19.5 Remove the Drain Pan
19.6 Remove the Cross Flow Fan and Fan Motor
1. Release the 2 screws to remove the Drain Pan.
Drain Pan
1. Release the 3 screws
from the particular piece
Evaporator.
Evaporato
r
