-18-
Parts List
REPLACEMENT PARTS LIST
Model: CT-2017F
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
091-02
PARTS LIST
IC006 MN1280R IC, RESET
IC050 TC74HC4066AL IC, HALFTONE
IC451 LA7837-TV IC, VERTICAL OUT
IC551 AN78M09LB IC, VOLTAGE REGULATOR 9V
IC552 AN78M05LB IC, VOLTAGE REGULATOR, 5V
IC553 AN78M05LB
IC, VOLTAGE REGULATOR,
STBY
IC801 STRG5623A IC POWER SUPPLY, 360V
IC2201 AN5829S-E1V IC, MTS, S-AGC
IC2301 AN17800A IC, AUDIO AMP
IC2302 AN17800A IC, AUDIO AMP
COILS
L001 EXCELSA35T FERRITE BEAD
L003 TLUABTA2R2K COIL, PEAKING 2.2UH
L004 TLUABTA2R2K COIL, PEAKING 2.2UH
L005 EXCELDR35V FERRITE BEAD
L006 EXCELSA24T FERRITE BEAD
L007 EXCELDR35V FERRITE BEAD
L008 TLUABTA470K COIL, PEAKING 47UH
L009 EXCELSA35V FERRITE BEAD
L010 ELESN330JA COIL, PEAKING 33UH
L011 ELESN330JA COIL, PEAKING 33UH
L013 EXCELDR35V FERRITE BEAD
L014 ELESN180KA COIL, PEAKING 18UH
L015 EXCELSA35V FERRITE BEAD
L016 EXCELSA35V FERRITE BEAD
L017 TLUABTA100K COIL, PEAKING 10UH
L018 TLUABTA150K COIL, PEAKING 15UH
L019 EXCELDR35V FERRITE BEAD
L090 EXCELSA24T FERRITE BEAD
L104 TLUABTA2R2K COIL, PEAKING 2.2UH
L108 EXCELSA35V FERRITE BEAD
L238 EXCELSA39V FERRITE BEAD
L245 EXCELSA35V FERRITE BEAD
L250 EXCELSA35V FERRITE BEAD
L306 TLUABTA2R2K COIL, PEAKING 2.2UH
L325 EXCELSA35V FERRITE BEAD
L403 TLUABTA2R2K COIL, PEAKING 2.2UH
L416 EXCELSA39V FERRITE BEAD
L551 ELH5L4101 COIL
L801 ELF15N011A COIL
L802 ELEIE680KA COIL, PEAKING 68UH
L803 TALL08T680KA LINE FILTER
L804 EXCELDR35V FERRITE BEAD
L805 TALL08T220KA TRANSFORMER, LINE FILTER
L2305 EXCELSA35V FERRITE BEAD
L2308 EXCELSA24V FERRITE BEAD
L2350 ELESN4R7JA COIL, PEAKING 4.7UH
TRANSISTORS
Q001 2SD601ARTX TRANSISTOR
Q006 2SB709ARTX TRANSISTOR
REF NO. PART NO. DESCRIPTION
Q007 2SB709ARTX TRANSISTOR
Q008 2SB709ARTX TRANSISTOR
Q009 2SC1473A TRANSISTOR
Q050 2SB709ARTX TRANSISTOR
Q051 2SB709ARTX TRANSISTOR
Q052 2SB709ARTX TRANSISTOR
Q053 2SD601ARTX TRANSISTOR
Q054 2SD601ARTX TRANSISTOR
Q055 2SD601ARTX TRANSISTOR
Q090 2SB709ARTX TRANSISTOR
Q092 2SB709ARTX TRANSISTOR
Q351 2SC3063RL TRANSISTOR
Q352 2SC3063RL TRANSISTOR
Q353 2SC3063RL TRANSISTOR
Q354 2SD601ARTX TRANSISTOR
Q355 2SD601ARTX TRANSISTOR
Q356 2SD601ARTX TRANSISTOR
Q451 2SD601ARTX TRANSISTOR
Q452 2SD601ARTX TRANSISTOR
Q453 2SD601ARTX TRANSISTOR
Q501 2SC1573AH TRANSISTOR
Q505 2SD601ARTX TRANSISTOR
Q520 2SD601ARTX TRANSISTOR
Q551 2SC562200VLA TRANSISTOR
Q605 2SB709ARTX TRANSISTOR
Q606 2SD601ARTX TRANSISTOR
Q820 2SA1767QTA TRANSISTOR
Q830 2SB1011QRL TRANSISTOR
Q2350 2SB709ARTX TRANSISTOR
RELAYS
RL801 TSEH0005 RELAY
RESISTORS
R001 ERJ6GEYJ102V RES,M 1K-J-1/10W
R003 ERJ6GEYJ105V RES,M 1M-J-1/10W
R004 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R006 ERDS2TJ101T RES,C 100-J-1/4W
R007 ERJ6GEYJ471V RES,M 470-J-1/10W
R008 ERJ6GEYJ471V RES,M 470-J-1/10W
R009 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R010 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R011 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R012 ERJ6GEYJ473V RES,M 47K-J-1/10W
R013 ERJ6GEYJ202V RES,M 2K-J-1/10W
R014 ERJ6GEYJ221V RES,M 220-J-1/10W
R015 ERJ6GEYJ221V RES,M 220-J-1/10W
R016 ERJ6GEYJ221V RES,M 220-J-1/10W
R017 ERJ6GEYJ681V RES,M 680-J-1/10W
R018 ERJ6GEYJ681V RES,M 680-J-1/10W
R019 ERJ6GEYJ681V RES,M 680-J-1/10W
R021 ERJ6GEYJ101V RES,M 100-J-1/10W
R022 ERJ6GEYJ101V RES,M 100-J-1/10W
REF NO. PART NO. DESCRIPTION
