-7-
Receiver Feature Table
*Note: When ordering a Board, add and ” S” after the Board suffix application.
Example, If Order A-Board for CT-2017F, should be ordered as: TNP2AH040S.
FEATURE\MODEL CT-2017F
Chassis No AP391
Family NA7DM
Receiving System NTSC
# of channels 181
Menu language ENG/SPN/FRN
Closed Caption X
V-Chip USA/CANADA
75 Ω input X
Remote Model # EUR501450
Picture tube Type PANABLACK
Picture tube Supplier SAMSUNG
Comb Filter 2DIG
V/A norm V
MTS/SAP/DBX X
Built-in audio power 1.5Wx2 (10%)
# of speakers 2
AI Sound X
A/V in (rear/front) 1(1/1)
EPJ/HPJ/MISC HPJ
Dimensions mm
(WxDxH) in
515.7x490.5x461.7
20.30x19.31x18.17
Weight (kg/lbs) 20/44.09
Power source (V/Hz) 120/60
Anode voltage
26.6
±1.25 kV
Video input jack 1Vp-p 75Ω, phono
Audio input jack 500mV rms, 47KΩ
A-Board TNP2AH040 DH*
C-Board TNP2AA106 AF*
Table 1. Receiver Features
Specifications are subject to change without notice or obligation.
Dimensions and weights are approximate.
