-20-
Parts List
REPLACEMENT PARTS LIST
Model: CT-2017F
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
091-02
PARTS LIST
R562 ERG3FJ680H RES,M 68-J-3W
R563 ERG1SJ150P RES,M 15-J-1W
R567 ERG2FJ122H RES,M 12K-J-2W
R572 ERJ6GEYJ222V RES,M 2.2K-J-1/10W
R605 ERDS2TJ103T RES,C 10K-J-1/4W
R606 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R607 ERJ6GEYJ102V RES,M 1K-J-1/10W
R608 ERJ6GEYJ104V RES,M 100K-J-1/10W
R801 ERF7ZK1R5 RES,W 1.5-K-7W
R802 ERDS2TJ684T RES,C 680K-J-1/4W
R803 ERG2FJ100H RES,M 10K-J-1/2W
R804 ERG2FJ104H RES,M 100K-J-2W
R805 ERX2FZJR18H RES,M .18-J-2W
R806 ERX2FJR56H RES,M .56-J-2W
R807 ERDS2TJ681T RES,C 680-J-1/4W
R808 ERDS2TJ4R7T RES,C 4.7-J-1/4W
R809 ERDS2TJ472T RES,C 4.7K-J-1/4
R815 ERC12ZGM825D RES,S 8.2MEG-M-1/2
R817 ERX3FJ6R8 RES,M 6.8-J-3W
R821 ERDS1FJ1R5T RES,C 1.5-J-1/2W
R822 ERDS1FJ1R5T RES,C 1.5-J-1/2W
R823 ERDS1FJ272T RES,C 2.7K-J-1/2W
R824 ERDS2TJ223T RES,C 22K-J-1/4W
R825 ERDS2TJ272T RES,C 2.7K-J-1/4W
R828 ERJ6GEYJ104V RES,M 100K-J-1/10W
R830 ERDS2TJ104T RES,C 100K-J-1/4W
R831 ERDS2TJ682T RES,C 6.8K-J-1/4W
R850 ERQ12HJR56P RES,F .56-J-1/2W
R2201 ERJ6GEYJ224V RES,M 220K-J-1/10W
R2203 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2204 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2205 ERJ6GEYJ101V RES,M 100-J-1/10W
R2206 ERJ6GEYJ273V RES,M 27K-J-1/10W
R2301 ERQ2CJP3R9S RES,F 3.9-J-2W
R2307 ERJ6GEYJ103V RES,M 10K-J-1/10W
R2350 ERDS2TJ391T RES,C 390-J-1/4W
R2351 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R2352 ERJ6GEYJ683V RES,M 68K-J-1/10W
R2353 ERJ6GEYJ124V RES,M 120K-J-1/10W
R2354 ERJ6GEYJ123V RES,M 12K-J-1/10W
R2355 ERJ6GEYJ222V RES,M 2.2K-J-1/10W
R2356 ERJ6GEYJ101V RES,M 100-J-1/10W
R2357 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R2365 ERDS2TJ102T RES,C 1K-J-1/4W
R2370 ERJ6GEYJ103V RES,M 10K-J-1/10W
R3001 ERDS2TJ101T RES,C 100-J-1/4W
R3005 ERJ6GEYJ334V RES,M 330K-J-1/10W
R3007 ERJ6GEYJ151V RES,M 150-J-1/10W
R3008 ERJ6GEYJ151V RES,M 150-J-1/10W
R3009 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3010 ERJ6GEYJ334V RES,M 330K-J-1/10W
REF NO. PART NO. DESCRIPTION
R3011 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3016 ERDS2TJ181T RES,C 180-J-1/4W
R3017 ERDS2TJ181T RES,C 180-J-1/4W
R3018 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3019 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
SWITCHES
S001 EVQPF106K SWITCH
S002 EVQPF106K SWITCH
S003 EVQPF106K SWITCH
S004 EVQPF106K SWITCH
S005 EVQPF106K SWITCH
S008 EVQPF106K SWITCH
S009 EVQPF106K SWITCH
TRANSFORMERS
T501 TLH15452
TRANSFORMER, HORIZONTAL
DRIVER
T551 KFT3AA341F TRANSFORMER, FLYBACK
T801 ETS29AS183NC TRANSFORMER
CRYSTALS
X001 TSSA092 CRYSTAL OSCILLATOR
X002 AF080005BE CRYSTAL
OTHERS
TNR001 ENG36604GR TUNER
M001 TSX2AA0111-1 A/C LINE CORD
M002 A51KRE89XDT CRT 20"
M003 TXF3A011DB2 ASSY. DAG GROUND
M004 TJSC00300 CRT SOCKET
DY TLY2AA001 DEFLECTION YOKE
M005 JH291U-009 YOKE, CONVERGENCE
M006 0FMK014ZZ
CONVERGENCE CORRECTOR
STRIP
M007 TMM2A30702 WEDGE, YOKE
DEG TSP2AA008 COIL, DEGAUSSING 20
M008 TXFKU06BSER
ASSY, CABINET BACK
(Cabinet Back, Double Insul.
Label, Felt, Label FCC, Label
X-Ray Warning)
M009 TXFKY06ESER
ASSY, CABINET FRONT 20"
(Cabinet Front 20”, Guide IR,
Badge Panasonic, Label X-Ray
Warning)
M010 TAS2AA0012 SPEAKER 16-OHM 1.5W
M011 TKX2AA00401 GUIDE, IR
M012 TBX2AA1701GS BUTTON, 7-KEY
JK3001 TJB2A9064B ASSY. JACK A/V
JK3002 TJB2AA0046 TERMINAL, FRONT A/V
ACCESORIES
M013 EUR501450 REMOTE CONTROL
M014 UR50EC1190A
BATTERY COVER, REMOTE
CONTROL
M015 TQB2AA0370 OWNERS MANUAL
REF NO. PART NO. DESCRIPTION
To Next Page
