-24-
Parts List
REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
042-02
PARTS LIST
R360 ERDS2TJ101T
RES,C 100-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R360 ERDS2TJ821T
RES,C 820-J-1/4W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
R361 ERDS2TJ821T
RES,C 820-J-1/4W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
R362 ERDS2TJ821T
RES,C 820-J-1/4W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
R363 ERDS2TJ101T RES,C 100-J-1/4W
R364 ERDS2TJ101T RES,C 100-J-1/4W
R365 ERDS2TJ101T
RES,C 100-J-1/4W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
R367 ERDS2TJ221T
RES,C 220-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R368 ERDS2TJ221T
RES,C 220-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R369 ERDS2TJ221T
RES,C 220-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R370 ERDS2TJ101T
RES,C 100-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R371 ERDS2TJ751T
RES,C 750-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R372 ERDS2TJ751T
RES,C 750-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R373 ERDS2TJ751T
RES,C 750-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R374 ERG2FJ223H
RES,M 22K-J-2W
CT-36D12DF/DUF CT-36D32F/UF
R375 ERG2FJ223H
RES,M 22K-J-2W
CT-36D12DF/DUF CT-36D32F/UF
R376 ERG2FJ223H
RES,M 22K-J-2W
CT-36D12DF/DUF CT-36D32F/UF
R377 ERG2FJ223H
RES,M 22K-J-2W
CT-36D12DF/DUF CT-36D32F/UF
R378 ERG2FJ223H
RES,M 22K-J-2W
CT-36D12DF/DUF CT-36D32F/UF
R379 ERG2FJ223H
RES,M 22K-J-2W
CT-36D12DF/DUF CT-36D32F
R380 ERDS2TJ330T
RES,C 33-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R381 ERDS2TJ330T
RES,C 33-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R382 ERDS2TJ330T
RES,C 33-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R383 ERDS2TJ330T
RES,C 33-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
REF
NO.
PART NO. DESCRIPTION
R384 ERDS2TJ330T
RES,C 33-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R385 ERDS2TJ330T
RES,C 33-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R386 ERDS2TJ752T
RES,C 7.5K-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R387 ERDS2TJ752T
RES,C 7.5K-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R388 ERDS2TJ752T
RES,C 7.5K-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R389 ERDS1TJ272T
RES,C 2.7K-J-1/2W
CT-36D12DF/DUF CT-36D32F/UF
R390 ERDS1TJ272T
RES,C 2.7K-J-1/2W
CT-36D12DF/DUF CT-36D32F/UF
R391 ERDS1TJ272T
RES,C 2.7K-J-1/2W
CT-36D12DF/DUF CT-36D32F/UF
R401 ERJ6GEYJ102V RES,M 1K-J-1/10W
R402 ERJ6GEYJ471V RES,M 470-J-1/10W
R403 ERJ6GEYJ622V RES,M 6.2K-J-1/10W
R405 ERJ6GEYJ102V RES,M 1K-J-1/10W
R408 ERJ6GEYJ331V RES,M 330-J-1/10W
R409 ERJ6GEYJ271V RES,M 270-J-1/10W
R410 ERJ6ENF1272V RES,M 12.7K-F-1/10W
R411 ERJ6ENF6801V RES,M 6.8K-F-1/10W
R412 ERDS2TJ123T RES,C 12K-J-1/4W
R452 ERDS1FJ1R8P RES,C 1.8-J-1/2W
R453 ERJ6GEYJ123V RES,M 12K-J-1/10W
R454 ERJ6GEYJ473V RES,M 47K-J-1/10W
R455 ERJ6GEYJ103V RES,M 10K-J-1/10W
R456 ERG3FJ151H RES,M 150-J-3W
R457 ERDS1FJ1R5P RES,C 1.5-J-1/2W
R458 ERDS1FJ2R7P RES,C 2.7-J-1/2W
R459 ERDS2TJ122T RES,C 1.2K-J-1/4W
R460 ERJ6GEYJ103V RES,M 10K-J-1/10W
R461 ERJ6GEYJ223V RES,M 22K-J-1/10W
R465 ERJ6GEYJ104V RES,M 100K-J-1/10W
R468 ER0S2THF4321 RES,M 4.32K-F-1/4W
R469 ER0S2THF1471 RES,M 1.47K-F-1/4W
R470 ERDS2TJ102T RES,C 1K-J-1/4W
R501 ERJ6GEYJ301V RES,M 300-J-1/10W
R502 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R504 ERJ6GEYJ333V RES,M 33K-J-1/10W
R505 ERDS1TJ181T RES,C 180-J-1/2W
R506 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R507 ERJ6GEYJ561V RES,M 560-J-1/10W
R508 ERJ6GEYJ471V RES,M 470-J-1/10W
R509 ERJ6GEYJ221V RES,M 220-J-1/10W
R510 ERG3FJ152H
RES,M 1.5K-J-3W
CT-36D12DF/DUF CT-36D32F/UF
R510 ERG3FJ202H
RES,M 2K-J-3W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
REF
NO.
PART NO. DESCRIPTION
