REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
-25-
042-02
PARTS LIST
Parts List
R510 ERG3FJ222H
RES,M 2200-J-3W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
R511 ERG3FJ152H
RES,M 1.5K-J-3W
CT-36D12DF/DUF CT-36D32F/UF
R511 ERG3FJ202H
RES,M 2K-J-3W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
R511 ERG3FJ272H
RES,M 2.7K-J-3W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
R512 ERG2FJ392H RES,M 3.9K-J-2W
R513 ERJ6GEYJ471V RES,M 470-J-1/10W
R514 ERJ6GEYJ102V
RES,M 1K-J-1/10W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R514 ERJ6GEYJ152V
RES,M 1.5K-J-1/10W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
R515 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R516 ERJ6GEYJ272V RES,M 2.7K-J-1/10W
R517 ERJ6GEYJ181V RES,M 180-J-1/10W
R531 ERD25FJ470P RES,C 47-J-1/4W
R532 ERJ6ENF5362V
RES,M 53.6K-F-1/10W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R532 ERJ6ENF5602V
RES,M 56K-F-1/10W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
R533 ERJ6ENF1692V
RES,M 16.9K-F-1/10W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R533 ERJ6ENF2102V
RES,M 21K-F-1/10W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
R550 ERDS1FJ1R0P
RES,C 1.0-J-1/2W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
R551 ERDS1FJ1R0P RES,C 1.0-J-1/2W
R552 ERDS1FJ1R0T RES,C 1.0-J-1/2W
R553 ERG3FJ270H RES,M 27-J-3W
R556 ERJ6GEYJ272V RES,M 2.7K-J-1/10W
R557 ERJ6GEYJ103V RES,M 10K-J-1/10W
R558 ERQ1CZKPR22S
RES,F .22-K-1W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
R558 ERQ2CJP1R3S
RES,F 1.3-J-2W
CT-36D12DF/DUF CT-36D32F/UF
R558 ERQ2CJP1R8S
RES,F 1.8-J-2W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
R559 ERG2FJ683H RES,M 12K-J-2W
REF
NO.
PART NO. DESCRIPTION
R560 TLTABT101K
COIL, PEAKING
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
R561 ERG2FJ102H RES,M 1K-J-2W
R563 ERDS2TJ683T RES,C 68K-J-1/4W
R564 ERDS2TJ563T
RES,C 56K-J-1/4W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R564 ERDS2TJ823T
RES,C 82K-J-1/4W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
R566 ERDS1FJ1R0P RES,C 1.0-J-1/2W
R569 ERG2FJ683H
RES,M 12K-J-2W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R573 ERG3FJ180H
RES,M 18-J-3W
CT-32D32F/UF CT-36D32F/UF
R573 ERG3FJ220H
RES,M 22-J-3W
CT-2707DF/DUF CT-3207DF/DUF
SP-3235F/UF
R574 ERG2FJ220H
RES,M 22-J-2W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF
R574 ERG2FJ270H
RES,M 27-J-2W
CT-27D12DF/DUF CT-32D12DF/DUF
CT-36D12DF/DUF
R601 ERJ6GEYJ391V RES,M 390-J-1/10W
R618 ERJ6GEYJ474V RES,M 470K-J-1/10W
R619 ERJ6GEYJ563V RES,M 56K-J-1/10W
R620 ERJ6GEYJ153V RES,M 15K-J-1/10W
R752 ERDS2TJ333T
RES,C 33K-J-1/4W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R753 ERDS2TJ103T
RES,C 10K-J-1/4W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R754 ERG3FJ562
RES,M 5.6K-J-3W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R755 ERDS2TJ563T
RES,C 56K-J-1/4W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R756 ERDS2TJ103T
RES,C 10K-J-1/4W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R757 ERDS2TJ224T
RES,C 220K-J-1/4W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
REF
NO.
PART NO. DESCRIPTION
