-28-
Parts List
REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
042-02
PARTS LIST
R2106 ERJ6GEYJ183V
RES,M 18K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2109 ERJ6GEYJ683V
RES,M 68K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2110 ERJ6GEYJ331V
RES,M 330-J-1/10W
CT-27D32F/UFCT-32D32F/UF
CT-36D32F/UF
R2111 ERJ6GEYJ152V
RES,M 1.5K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2112 ERJ6GEYJ331V
RES,M 330-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2113 ERJ6GEYJ102V
RES,M 1K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2114 ERJ6GEYJ681V
RES,M 680-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2116 ERJ6GEYJ102V
RES,M 1K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2117 ERJ6GEYJ121V
RES,M 120-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2118 EVND8AA03B14
CONTROL 10K
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2119 ERJ6GEYJ392V
RES,M 3.9K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2121 ERJ6GEYJ221V
RES,M 220-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2122 ERJ6GEYJ473V
RES,M 47K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2123 ERJ6GEYJ473V
RES,M 47K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2124 ERJ6GEYJ332V
RES,M 3.3K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2127 ERJ6GEYJ101V
RES,M 100-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R2203 ERJ6GEYJ751V RES,M 750-J-1/10W
R2206 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2207 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2221 ERJ6GEYJ101V RES,M 100-J-1/10W
R2301 ERQ2CJP2R2S RES,F 2.2-J-2W
R2305 ERD25FJ180T RES,C 18-J-1/4
R2306 ERD25FJ180T RES,C 18-J-1/4
R2307 ERJ6GEYJ221V RES,M 220-J-1/10W
R2308 ERJ6GEYJ221V RES,M 220-J-1/10W
R2311 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
REF
NO.
PART NO. DESCRIPTION
R2312 ERJ6GEYJ752V RES,M 7.5K-J-1/10W
R2313 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R2318 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R2319 ERJ6GEYJ223V RES,M 22K-J-1/10W
R2321 ERDS2TJ181T
RES,C 180-J-1/4W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
R2322 ERDS2TJ181T
RES,C 180-J-1/4W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
R2323 ERJ6GEYJ822V RES,M 8.2K-J-1/10W
R2325 ERJ6GEYJ103V RES,M 10K-J-1/10W
R2329 ERJ6GEYJ751V RES,M 750-J-1/10W
R2330 ERJ6GEYJ183V RES,M 18K-J-1/10W
R2332 ERJ6GEYJ751V RES,M 750-J-1/10W
R2333 ERJ6GEYJ183V RES,M 18K-J-1/10W
R2334 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R2336 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R2337 ERJ6GEYJ221V RES,M 220-J-1/10W
R2338 ERJ6GEYJ103V RES,M 10K-J-1/10W
R2339 ERJ6GEYJ221V RES,M 220-J-1/10W
R2340 ERJ6GEYJ223V RES,M 22K-J-1/10W
R2341 ERJ6GEYJ152V RES,M 1.5K-J-1/10W
R2342 ERJ6GEYJ223V RES,M 22K-J-1/10W
R2343 ERJ6GEYJ152V RES,M 1.5K-J-1/10W
R2344 ERJ6GEYJ471V RES,M 470-J-1/10W
R2345 ERJ6GEYJ223V
RES,M 22K-J-1/10W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
R2345 ERJ6GEYJ561V
RES,M 560-J-1/10W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
R2346 ERJ6GEYJ471V RES,M 470-J-1/10W
R2350 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R2351 ERJ6GEYJ105V RES,M 1M-J-1/10W
R2352 ERJ6GEYJ105V RES,M 1M-J-1/10W
R2353 ERJ6GEYJ101V RES,M 100-J-1/10W
R2355 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R2418 ERJ6GEYJ471V RES,M 470-J-1/10W
R2419 ERJ6GEYJ471V RES,M 470-J-1/10W
R3001 ERJ6GEYJ101V RES,M 100-J-1/10W
R3003 ERJ6GEYJ152V
RES,M 1.5K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
R3004 ERJ6GEYJ152V
RES,M 1.5K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
REF
NO.
PART NO. DESCRIPTION
