REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
-29-
042-02
PARTS LIST
Parts List
R3005 ERJ6GEYJ330V
RES,M 33-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
R3006 ERJ6GEYJ750V
RES,M 75-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
R3007 ERJ6GEYJ750V RES,M 75-J-1/10W
R3008 ERJ6GEYJ750V RES,M 75-J-1/10W
R3009 ERJ6GEYJ750V RES,M 75-J-1/10W
R3010 ERJ6ENF75R0V RES,M 75.0-F-1/10W
R3011 ERJ6ENF75R0V RES,M 75.0-F-1/10W
R3012 ERJ6GEYJ750V RES,M 75-J-1/10W
R3013 ERDS2TJ331T RES,C 330-J-1/4W
R3014 ERJ6GEYJ330V RES,M 33-J-1/10W
R3015 ERDS2TJ102T RES,C 1K-J-1/4W
R3016 ERJ6GEYJ102V RES,M 1K-J-1/10W
R3017 ERJ6GEYJ330V RES,M 33-J-1/10W
R3018 ERJ6GEYJ102V RES,M 1K-J-1/10W
R3019 ERDS2TJ102T RES,C 1K-J-1/4W
R3020 ERJ6GEYJ330V RES,M 33-J-1/10W
R3021 ERJ6GEYJ331V
RES,M 330-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R3290 ERDS2TJ821T
RES,C 820-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R3291 ERDS2TJ332T
RES,C 3.3K-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R3293 ERDS2TJ561T
RES,C 560-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R3294 ERDS2TJ101T
RES,C 100-J-1/4W
CT-36D12DF/DUF CT-36D32F/UF
R4310 ERJ6GEYJ102V
RES,M 1K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4311 ERJ6GEYJ102V
RES,M 1K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4326 ERD25VJ221T
RES,C 220-J-1/4
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4327 ERJ6GEYJ331V
RES,M 330-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4328 ERJ6GEYJ560V
RES,M 56-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
REF
NO.
PART NO. DESCRIPTION
R4329 ERJ6GEYJ182V
RES,M 1.8K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4330 ERJ6GEYJ561V
RES,M 560-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4331 ERJ6GEYJ391V
RES,M 390-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4332 ERJ6GEYJ393V
RES,M 39K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4333 ERJ6GEYJ304V
RES,M 300K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4334 ERJ6GEYJ152V
RES,M 1.5K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4336 ERJ6GEYJ680V
RES,M 68-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4338 ERJ6GEYJ222V
RES,M 2.2K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4339 ERJ6GEYJ102V
RES,M 1K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4340 ERJ6GEYJ682V
RES,M 6.8K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4341 ERJ6GEYJ222V
RES,M 2.2K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4342 ERJ6GEYJ223V
RES,M 22K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4344 ERJ6GEYJ682V
RES,M 6.8K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R4345 ERJ6GEYJ103V
RES,M 10K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
R6501 ERJ6GEYJ471V RES,M 470-J-1/10W
R6502 ERJ6GEYJ471V RES,M 470-J-1/10W
R6503 ERJ6GEYJ471V RES,M 470-J-1/10W
R6505 ERJ6GEYJ471V RES,M 470-J-1/10W
REF
NO.
PART NO. DESCRIPTION
