-30-
Parts List
REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
042-02
PARTS LIST
R6509 ERJ6GEYJ471V RES,M 470-J-1/10W
R6510 ERJ6GEYJ102V RES,M 1K-J-1/10W
R6511 ERJ6GEYJ123V RES,M 12K-J-1/10W
R6512 ERJ6GEYJ102V RES,M 1K-J-1/10W
R6513 ERJ6GEYJ152V RES,M 1.5K-J-1/10W
R6515 ERJ6GEYJ102V RES,M 1K-J-1/10W
R6516 ERJ6GEYJ103V RES,M 10K-J-1/10W
R6518 ERJ6GEYJ333V RES,M 33K-J-1/10W
R6519 ERJ6GEYJ333V RES,M 33K-J-1/10W
R6520 ERJ6GEYJ102V RES,M 1K-J-1/10W
R6522 ERJ6GEYJ102V RES,M 1K-J-1/10W
R6523 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R6524 ERJ6GEYJ471V RES,M 470-J-1/10W
R6526 ERJ6GEYJ102V RES,M 1K-J-1/10W
R6535 ERJ6GEYJ181V RES,M 180-J-1/10W
R6537 ERJ6GEYJ392V RES,M 3.9K-J-1/10W
R6538 ERJ6GEYJ122V RES,M 1.2K-J-1/10W
R6540 ERJ6GEYJ151V RES,M 150-J-1/10W
R6542 ERJ6GEYJ680V RES,M 68-J-1/10W
R6543 ERJ6GEYJ122V RES,M 1.2K-J-1/10W
R6544 ERJ6GEYJ102V RES,M 1K-J-1/10W
R6545 ERJ6GEYJ221V RES,M 220-J-1/10W
R6548 ERJ6GEYJ471V RES,M 470-J-1/10W
R6549 ERJ6GEYJ222V RES,M 2.2K-J-1/10W
R6553 ERJ6GEYJ101V RES,M 100-J-1/10W
R6554 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R6555 ERJ6GEYJ153V RES,M 15K-J-1/10W
R6556 ERJ6GEYJ333V RES,M 33K-J-1/10W
R6557 ERJ6GEYJ123V RES,M 12K-J-1/10W
R6558 ERJ6GEYJ103V RES,M 10K-J-1/10W
R6559 ERJ6GEYJ272V RES,M 2.7K-J-1/10W
R6560 ERJ6GEYJ124V RES,M 120K-J-1/10W
R6565 ERJ6GEYJ102V RES,M 1K-J-1/10W
R6566 ERJ6GEYJ681V RES,M 680-J-1/10W
R6567 ERJ6GEYJ561V RES,M 560-J-1/10W
R6568 ERJ6GEYJ471V RES,M 470-J-1/10W
SWITCHES
S001 TSE2AD001 SWITCH, PUSH
S002 TSE2AD001 SWITCH, PUSH
S003 TSE2AD001 SWITCH, PUSH
S004 TSE2AD001 SWITCH, PUSH
S005 TSE2AD001 SWITCH, PUSH
S008 TSE2AD001 SWITCH, PUSH
S009 TSE2AD001 SWITCH, PUSH
TRANSFORMERS
T001 TLP16297 TRANSFORMER, POWER SUPPLY
T501 TLH15452 TRANSFORMER, HORIZONTAL DRIVER
T502 ETE19Z30DY TRANSFORMER
T551 KFT6AB056F
TRANSFORMER (FBT)
CT-36D12DF/DUF CT-36D32F/UF
REF
NO.
PART NO. DESCRIPTION
T551 TLF2AA002
TRANSFORMER, FLYBACK
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
T551 TLF2AA003
TRANSFORMER, FLYBACK
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
T751 ETE19Z30EY
TRANSFORMER
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
T801 ETS29AK3L5NC
TRANSFORMER, SWITCHING
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
T801 ETS29AK3M5NC
TRANSFORMER, SWITCHING
CT-36D12DF/DUF CT-36D32F/UF
T801 TLP2AA003
TRANSFORMER
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
CRYSTALS / FILTERS
X001 TSSA092 CRYSTAL OSCILLATOR
X501 TSS2AA001 CRYSTAL, 3.58MHZ
X601 TAFCSB503F30 CRYSTAL
X1801 TSSA092
CRYSTAL OSCILLATOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
X2102
EFCS4R5MW5B
A
FILTER, BANDPASS
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
X2103 M1972M
FILTER
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
OTHERS
TNR001 ENGF6101G
TUNER
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
TNR001 ENG36604GR
TUNER
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-32D12DF/DUF
CT-36D12DF/DUF SP-3235F/UF
TNR002 ENV56D61G3
TUNER
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
M001 TSX2AA0111-1
A/C LINE CORD
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF
SP-3235F/UF
M002 TSX2AA0112-1
A/C LINE CORD
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF CT-36D12DF/DUF
CT-36D32F/UF
M003 A90LLD361X
CRT 36”
CT-36D12DF/DUF CT-36D32F/UF
M004 M68LGL061X
CRT 27”
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
M005 M80JUA061X
CRT 32”
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
REF
NO.
PART NO. DESCRIPTION
