REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
-31-
042-02
PARTS LIST
Parts List
M006 TJSC00300 CRT SOCKET
DY KDY42L632F
YOKE, DEFLECTION
CT-36D12DF/DUF CT-36D32F/UF
DY TLY2AA006
DEFLECTION YOKE
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
DY TLY2AA008
DEFLECTION YOKE
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
M007 JH291U-009
YOKE, CONVERGENCE
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
M008 TP-11900PLX
CONVERGENCE YOKE
CT-36D12DF/DUF CT-36D32F/UF
M009 TMM2A30702 WEDGE, YOKE
DEG TLK2AA0011
COIL, DEGAUSSING
CT-27D12DF/DUF CT-27D32F/UF
DEG TSP2AA017 COIL, DEGAUSSING CT-2707DF/DUF
M010 TXANV02ESER
REPAIR KIT (DEG. COIL)
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
M011 TXANV04ESER
REPAIR KIT (DEG. COIL)
CT-36D12DF/DUF CT-36D32F/UF
M012 0FMK014ZZ CONVERGENCE CORRECTOR STRIP
M013 TXF3A01AFRA
ASSY, DAG GND
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
M014 TXF3A011EV
ASSY., DAG GND
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
M015 TXF3A025QA
ASSY., DAG GND
CT-36D12DF/DUF CT-36D32F/UF
M016 TAS2AA0015
SPEAKER 8-OHM 5W
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
M017 TAS2AA0016
SPEAKER 8-OHM 5W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
M018 TBM2AA0021
BADGE, PANASONIC
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF
M019 TBM2A10141
BADGE, PANASONIC
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
M020 TBX2AA0121
BUTTON, 7-KEY
CT-27D12DF/DUF CT-27D32F/UF
M021 TBX2AA0131
BUTTON, 7-KEY
CT-32D12DF/DUF CT-32D32F/UF
M022 TBX2AA0141
BUTTON, 7-KEY
CT-36D12DF/DUF CT-36D32F/UF
M023 TBX2AA1001AG BUTTON, 7-KEY SP-3235F/UF
M024 TBX2AA1701GS
BUTTON, 7-KEY
CT-2707DF/DUF CT-3207DF/DUF
REF
NO.
PART NO. DESCRIPTION
M025 TXANV01ESER
7-KEY BUTTON
CT-27D12DF/DUF CT-27D32F/UF
M026 TEK6935
DOOR, CATCH
CT-36D12DF/DUF CT-36D32F/UF
M027 TKX2AA00401
GUIDE, IR
CT-2707DF/DUF CT-3207DF/DUF
M028 TKX2AA00404
GUIDE, IR
CT-27D12DF/DUF CT-27D32F/UF
M029 TKX2AA00405
GUIDE, IR
CT-32D12DF/DUF CT-32D32F/UF
M030 TKX2AA00406
GUIDE, IR
CT-36D12DF/DUF CT-36D32F/UF
M031 TKX2A3753 GUIDE, IR SP-3235F/UF
M032 TMW2A97121
STRAIN RELIEF: AC LINE CORD
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
M033 TBM17454-2 NAMEPLATE: QUASAR SP-3235F/UF
M034 TKP2AA00601
SMOKED SHEET
CT-36D12DF/DUF CT-36D32F/UF
SP-3235F/UF
M035 TXFKU02FSER ASSY, CABINET BACK SP-3235F/UF
M036 TXFKU09ESER
ASSY, CABINET BACK
CT-36D12DF/DUF CT-36D32F/UF
M037 TXFKU10ESER
ASSY, CABINET BACK
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF
M038 TXFKY02ESER
ASSY, CABINET FRONT CT-2707DF/
DUF
M039 TXFKY03ESER ASSY, CABINET BACK SP-3235F/UF
M040 TXFKY07FSER
ASSY, CABINET FRONT CT-3207DF/
DUF
M041 TXFKY11ESER
ASSY, CABINET FRONT
CT-32D12DF/DUF CT-32D32F/UF
M042 TXFKY12ESER
ASSY, CABINET FRONT
CT-36D12DF/DUF CT-36D32F/UF
JK3001 TJB2AA0221 TERMINAL, A/V 8P
JK3002 TJB2AA0045
TERMINAL, FRONT A/V
CT-36D12DF/DUF CT-36D32F/UF
JK3002 TJB2AA0046
TERMINAL, FRONT A/V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
JK3003 TJB2AA0171 TERMINAL, S-VHS
JK3004 TJB2AA0211-1 TERMINAL, A/V 2P
ACCESSORIES
M043 EUR511501 REMOTE CONTROL CT-3207DF/DUF
M044 EUR511511 REMOTE CONTROL CT-2707DF/DUF
M045 EUR511514
XMTR, REMOTE CONTROL
SP-3235F/UF
M046 EUR7613Z10
REMOTE CONTROL
CT-27D12DF/DUF CT-32D12DF/DUF
CT-36D12DF/DUF
M047 EUR7613Z30
XMTR, REMOTE CONTROL
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
REF
NO.
PART NO. DESCRIPTION
