14.1.4. Replacement Parts List (Indoor Unit)
Models:
CS-E15DKEW / CS-E15DKDW
REF. NO. PART NAME & DESCRIPTION QTY. CS-E15DKEW CS-E15DKDW REMARKS
1 CHASSY COMPLETE 1 CWD50C1431 ←
2 FAN MOTOR 1 CWA981149J ←
3 CROSS FOLW FAN COMPLETE 1 CWH02C1031 ←
4 BEARING ASS’Y 1 CWH64K007 ←
5 SCREW - CROSS FLOW FAN 1 CWH4580304 ←
6 EVAPORATOR 1 CWB30C1726 ←
7 FLARE NUT 1 CWT251030 (1/4") ←
8 FLARE NUT 1 CWT251032 (1/2") ←
9 HOLDER SENSOR 1 CWH32143 ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2343 ←
11 VERTICAL VANE 9 CWE241150 ←
12 CONNECTING BAR 1 CWE261072 ←
13 CONNECTING BAR 1 CWE261065 ←
14 AIR SWING MOTOR 2 CWA98260+MJ ←
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3849 ←
16 CAP - DRAIN TRAY 1 CWH521096 ←
17 HORIZONTAL VANE 1 CWE241173 ←
18 BACK COVER CHASSIS 1 CWD932454 ←
19 CONTROL BOARD CASING 1 CWH102259 ←
20 TERMINAL BOARD COMPLETE 1 CWA28C2082J ←
21 POWER SUPPLY CORD 1 — ←
22 ELECTRONIC CONTROLLER - MAIN 1 CWA73C1669 ←
23 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3977 ←
24 SENSOR COMPLETE 1 CWA50C2122 ←
25 CONTROL BOARD FRONT COVER 1 CWH13C1120 ←
26 INDICATOR COMPLETE 1 CWE39C1126-1 ←
27 INDICATOR HOLDER 1 CWD932429 ←
28 INDICATOR HOLDER 1 CWD932430 ←
29 CONTROL BOARD TOP COVER 1 CWH131207 ←
30 REMOTE CONTROL COMPLETE 1 CWA75C2616 ←
31 FRONT GRILLE COMPLETE 1 CWE11C3138 ←
32 INTAKE GRILLE 1 CWE22C1154 ←
33 GRILLE DOOR 1 CWE141073 ←
34 AIR FILTER 2 CWD001144 ←
35 SCREW - FRONT GRILLE 2 XTT4+16CFJ ←
36 CAP - FRONT GRILLE 2 CWH521109 ←
37 DRAIN HOSE 1 CWH851063 ←
38 INSTALLATION PLATE 1 CWH361067 ←
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ←
40 FULCRUM 1 CWH621046 ←
41 ELECTRONIC CONTROLLER - IONIZER 1 CWA743675 ←
42 CASING - IONIZER 1 CWD932464 ←
43 CASING - IONIZER 1 CWD932431 ←
44 ION GENERATOR 1 CWH94C0001 ←
45 SUPERSONIC AIR PURIFYING DEVICE 1 CWH91C1013 ←
46 ELECTRONIC CONTROLLER SUPERSONIC 1 CWA743874 ←
47 SUPER ALLERU BUSTER FILTER 1 CWD00C1133 ←
48 FRAME FR AIR FILTER SUPERSONIC 1 CWD011026 ←
49 RRAME FR AIR FILTER SUPERSONIC 1 CWD011027 ←
(Note)
• All parts are compliant with EU RoHS legislation.
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “
” marked parts are recommended to be kept in stock.
122
