14.1.6. Replacement Parts List (Indoor Unit)
Models:
CS-E18DKEW / CS-E18DKDW
REF. NO. PART NAME & DESCRIPTION QTY. CS-E18DKEW CS-E18DKDW REMARKS
1 CHASSY COMPLETE 1 CWD50C1382 ←
2 FAN MOTOR 1 CWA981149J ←
3 CROSS FOLW FAN COMPLETE 1 CWH02C1010 ←
4 SCREW - CROSS FLOW FAN 1 CWH551146 ←
5 BEARING ASS’Y 1 CWH64K007 ←
6 EVAPORATOR 1 CWB30C1533 ←
7 FLARE NUT 1 CWT251030 (1/4") ←
8 FLARE NUT 1 CWT251032 (1/2") ←
9 HOLDER SENSOR 1 CWH32143 ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2441 ←
11 VERTICAL VANE 15 CWE241088 ←
12 CONNECTING BAR 1 CWE261025 ←
13 AIR SWING MOTOR 1 CWA98260+MJ ←
13a LEAD WIRE - AIR SWING MOTOR 1 CWA67C3849 ←
14 AIR SWING MOTOR 1 CWA98K1008 ←
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3731 ←
16 HORIZONTAL VANE 1 CWE241152A ←
17 HORIZONTAL VANE 1 CWE241153A ←
18 CAP - DRAIN TRAY 1 CWH52C1001 ←
19 BACK COVER CHASSIS 1 CWD932162B ←
20 CONTROL BOARD CASING 1 CWH102250 ←
21 TERMINAL BOARD COMPLETE 1 CWA28C2082J ←
22 POWER SUPPLY CORD 1 — ←
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C1670 ←
24 INDICATOR COMPLETE 1 CWE39C1116 ←
25 INDICATOR HOLDER 1 CWD932435 ←
26 INDICATOR HOLDER 1 CWD932436 ←
27 SENSOR COMPLETE 1 CWA50C2122 ←
28 CONTROL BOARD TOP COVER 1 CWH131209 ←
29 CONTROL BOARD FRONT COVER 1 CWH131210 ←
30 REMOTE CONTROL COMPLETE 1 CWA75C2616 ←
31 FRONT GRILLE COMPLETE 1 CWE11C3160 ←
32 INTAKE GRILLE COMPLETE 1 CWE22C1159 ←
33 GRILLE DOOR 1 CWE141076 ←
34 AIR FILTER (L) 1 CWD001137 ←
35 AIR FILTER (R) 1 CWD001138 ←
36 SCREW - FRONT GRILLE 3 XTT4+16CFJ ←
37 CAP - FRONT GRILLE 3 CWH521062A ←
38 DRAIN HOSE 1 CWH851063 ←
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ←
40 INSTALLATION PLATE 1 CWH36K1007 ←
41 FULCRUM 2 CWH621047 ←
42 ELECTRONIC CONTROLLER - IONIZER 1 CWA743675 ←
43 CASING - IONIZER 1 CWD932464 ←
44 CASING - IONIZER 1 CWD932527 ←
45 ION GENERATOR 1 CWH94C0001 ←
46 SUPERSONIC AIR PURIFYING DEVICE 1 CWH91C1013 ←
47 ELECTRONIC CONTROLLER SUPERSONIC 1 CWA743874 ←
48 SUPER ALLERU BUSTER FILTER 1 CWD00C1133 ←
49 FRAME FR AIR FILTER SUPERSONIC 1 CWD011026 ←
50 RRAME FR AIR FILTER SUPERSONIC 1 CWD011027 ←
(Note)
• All parts are compliant with EU RoHS legislation.
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “
” marked parts are recommended to be kept in stock.
124
