14.3.2. Replacement Parts List (Indoor Unit)
Models:
CS-ME10DTEG / CS-E15DTEW / CS-E18DTEW
REF NO. PART NAME & DESCRIPTION QTY. CS-ME10DTEG CS-E15DTEW CS-E18DTEW REMARKS
1 CHASSY COMPLETE 1 CWD50C1419 ← ←
2 FAN MOTOR 1 CWA921158J ← ←
3 SUPPORTER FAN MOTOR 2 CWD932270 ← ←
4 BLOWER WHEEL ASS’Y 2 CWH01K1014 ← ←
5 AIR GUIDER B.W. 2 CWD321046 ← ←
6 CONTROL BOARD ASS’Y 1 CWH10K1055 ← ←
7 FLARE NUT (1/2") 1 CWT251032 ← ←
8 TERMINAL BOARD ASS’Y 1 CWA28K1036J ← ←
10 ELECTRONIC CONTROLLER 1 CWA73C1774 CWA73C1771 CWA73C1772
11 SENSOR ASS’Y COMP. 1 CWA50C2157 ← ←
12 LEAD WIRE FAN MOTOR 1 CWA67C4431 ← ←
13 LEAD WIRE FAN MOTOR 1 CWA67C4474 ← ←
14 EVAPORATOR 1 CWB30C1975 CWB30C1663 CWB30C1661
15 SUPPORTER TUBE ASS’Y 1 CWD932259 ← ←
16 FLARE NUT (1/4") 1 CWT251030 ← ←
17 DRAIN PAN COMPLETE 1 CWH40C1023 ← ←
18 TAP DRAIN TRAY 1 CWH401031 ← ←
19 DISCHARGE GRILLE COMPLETE 1 CWE20C2223 ← ←
20 DISCHARGE GRILLE 1 CWE201046 ← ←
21 VANE - AIR SWING 1 CWE241124 ← ←
22 CONNECTING BAR 2 CWE261052 ← ←
23 CONNECTING BAR 2 CWE261053 ← ←
24 VANE 14 CWE241126 ← ←
25 AIR SWING MOTOR 1 CWA981085J ← ←
26 INDICATOR COMP. 1 CWE39C1128 ← ←
28 CONTROL BOARD CASING ASS’Y 1 CWH13K1015 ← ←
31 INTAKE GRILLE COMPLETE 1 CWE22C1185 ← ←
32 AIR FILTER 2 CWJ0HBJY000003 ← ←
33 REMOTE CONTROL COMPLETE 1 CWA75C2610 ← ←
36 DRAIN HOSE 1 CWH85284 ← ←
37 INSTALLATION HOLDER 1 CWH361018 ← ←
38 ACCESSORY COMPLETE 1 CWH82C1286 ← ←
39 FULCRUM 3 CWH621030 ← ←
40 FRONT GRILLE COMPLETE 1 CWE11C3209 ← ←
41 STRING COMPLETE 1 CWH84C1006 ← ←
(Note)
• All parts are compliant with EU RoHS legislation.
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “
” marked parts are recommended to be kept in stock.
128
