14.4.4. Replacement Parts List (Indoor Unit Front Grille)
Model:
CZ-BT12DE (Front Grille Complete)
REF NO. PART NAME & DESCRIPTION QTY. PART NO. REMARKS
1 FRONT GRILLE - COMPLETE 1 CWE11C3105
2 FRONE - FRONT GRILLE CO. 1 CWE11C3353
4 A.S. MOTOR DC SINGLE 12V 250 OHM 2 CWA981105J
5 BRACKET - A.S. MOTOR 1 CWD932522
6 VANE 4 CWE241159
7 SHAFT 6 CWH631038
8 SHAFT 2 CWH631045
9 CONNECTOR - SHAFT 4 CWH081007
10 BEARING 6 CWH641008
11 LEAD WIRE - A.S. MOTOR 1 CWA67C5117
12 PLATE COVER FOR A.S. MOTOR 1 CWD911459
13 PLATE COVER FOR CONNECTING SHAFT 2 CWD911460
14 PLATE COVER FOR END SHAFT 1 CWD911461
21 ELECTRONIC CONT. (RECEIVER & INDICATOR) 1 CWA743610
22 LEAD WIRE - COMPLETE 1 CWA67C5576
24 INTAKE GRILLE 1 CWE221131
28 LEVER ARM 2 CWH651029
29 AIR FILTER 1 CWD001142
(Note)
• All parts are compliant with EU RoHS legislation.
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “
” marked parts are recommended to be kept in stock.
