3. Specifications
3.1 CU-3Z52TBE
Item Unit OUTDOOR UNIT
Indoor Unit Combination 1.6kW + 1.6kW + 2.0kW
Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit)
kW 5.20 (1.80 ~ 7.30)
Capacity
BTU/h 17700 (6140 ~ 24900)
Running Current A 5.00
Power Input W 1.09k (360 ~ 2.18k)
Electrical
Data
EER W/W 4.77 (5.00 ~ 3.35)
Annual Consumption kWh 214
Sound Pressure Level dB-A (H/L) 47 / -
Cooling Operation
Noise
Sound Power Level dB (H/L) 61 / -
kW 6.80 (1.60 ~ 8.30)
Capacity
BTU/h 23200 (5460 ~ 28300)
Running Current A 6.70
Power Input W 1.47k (320 ~ 2.17k)
Electrical
Data
COP W/W 4.63 (5.00 ~ 3.82)
Annual Consumption kWh 1667
Sound Pressure Level dB-A (H/L) 48 / -
Heating Operation
Noise
Sound Power Level dB (H/L) 62 / -
Maximum Current A 15.2
Maximum Input Power W 3.46k
Starting Current A 6.70
Capacity kW 3.95
Input Power W 1470
Extra Low Temperature
Cop W/W 2.69
Height mm 795
Width mm 875 (+95)
Dimension
Depth mm 320
Net Weight kg 71
Pipe Length Range (1 room) m 3 ~ 25
Maximum Pipe Length (Total Room) m 50
Standard Length m 5
Height Difference m 15
Add. Gas Amount g/m 20
Piping
Pipe Length for Add. Gas m 30
Liquid Side mm (inch) 6.35 (1/4)
Refrigerant Pipe Diameter
Gas Side mm (inch) 9.52 (3/8)
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Compressor
Rated Output W 1.30k
Type Propeller Fan
Motor Type DC Motor (8-poles)
Fan Motor
Rated Output W 60
Fan Speed High (Cooling / Heating) RPM 620 / 580
