Panasonic CU-3Z52TBE - Dimensions; Outdoor Unit Dimensions and Installation Space

89
4. Dimensions
59
27.5
(131)
613
875
131 95
38
83
132.5
360.5
41
<Top View>
320
795
<Side View><Side View> <Front View>
100 cm
10 cm
10 cm
Space necessary for
installation
Anchor Bolt Pitch
360.5 x 613
(25)
(81)
(167)
85.7x3=257.1
85.7x3=257.1
(210)
91.2
17
52
42
23.8
Unit: mm
